Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm

Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm

  • Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm
  • Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm
  • Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm
  • Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm
  • Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm
  • Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm
Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm
Product Details:
Place of Origin: Shaanxi, China
Brand Name: Razorlux
Certification: ce, LVD, RoHS, Saa, UL
Model Number: RGL2-400A
Payment & Shipping Terms:
Price: $767.00/Pieces
Packaging Details: 1.EPS Foam+carton(ONE UNIT PER CARTON) <br>2.Carton Size(mm):550*450*415mm<br>3.One 20'' Container can accept 250 Units
Contact Now
Detailed Product Description
Color Temperature(CCT): 2700-6500K, Cool White Lamp Luminous Efficiency(lm/w): 130, 130
Lighting Solutions Service: Lighting And Circuitry Design, DIALux Evo Layout Working Time (hours): 50000
Input Voltage(V): 80~315Vac, (347Vac Available On Request) Beam Angle(°): 40° 60° 120° 140°
Lamp Body Material: Aluminum Alloy Application: Sports Stadiums
Lamp Luminous Flux(lm): 52000lm, 52000lm Working Temperature(℃): -40C ~ 60C / -40F ~ 140F, -40 - 60
Warranty(Year): 5-Year Product Name: Stadium Lighting LED
IP Class: IP 65 (Upgradeable To IP 67) Luminous Efficacy(lm/w): 130
High Light:

140F Led Outdoor Sports Lighting

,

400W Led Outdoor Sports Lighting

,

RoHS led sports ground lighting

Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm 0

5 Years Warranty Round Waterproof IP67 Anti-exposure Outdoor 400W Stadium Lighting LED


Hockey rink lighting needs to illuminate all the fast-paced action that a hockey game delivers. After all, the puck is only 4” and can travel 100 mph. Whether attending a game in an arena or watching from home, the best viewing experience is one where the hockey rink is extremely well-lit.

LED lights provide energy efficient lighting that will decrease your energy consumption and costs, while increasing the light quality and providing even surface illumination for a whiter, brighter hockey arena.


Model

RGL2-400A
Beam Angle

40° 60° 120° 140°
Stable Flux (5700K after 1 hour)

52000lm
Dimension (mm)

468*388*367

Power Consumption
LEDs
360W

Driver
40W

Total
400W
Replace HID Lamp

800~1000W
Net Weight

15kg (33lbs)
Color Temperature

2700-6500K
Color Rendering

≥Ra75 (≥Ra80, ≥Ra90 available on request)
Working Life

≥50000Hrs
Housing Material

Aluminum & Powder coating
Power Supply

Meanwell
IP Class

IP 65 (Upgradeable to IP 67)
IK Class

IK 10
Insulation Class

Class I
Working Temperature

-40C ~ 60C / -40F ~ 140F
Working Humidity

10% ~ 95%
AC Input

110-480Vac input voltage without additional adapter
DC Input

100 ~ 400Vdc, 500Vdc ~ 800Vdc
THD

<10%
Power Factor

≥0.98

    Warranty
LED Module
5 years

Driver
5 years

Housing
10 years

Features:

✦ 80% lumen maintenance over 50,000hours.
✦ 110-480Vac input voltage without additional adapter.
✦ 0-10VDC, DALI and wireless control available.
✦ Photocell & motion sensor system available.
✦ Built-in surge protection & thermal protection.
✦ Mercury free, No UV or IR.
✦ High uniformity & color rendering index.
Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm 2Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm 3Round 140F Led Outdoor Sports Lighting Ground Stadiums 400W 52000lm 4

Features & Specifications of 1-10V Dimmable led flood light 400Watt

  • Patented Multi-function design, suitable for all working environments.
  • Rated Power: 400W-1200W
  • Input Voltage: AC90-305, DC127-431
  • Color Temperature: 2700K-6500K
  • Lamp Efficiency: 130LM/W
  • Beam Angle: 15°, 20°, 30°, 40°, 60°, 120°, 140°x60°.
  • CRI: Ra>75
  • IP Grade: IP65/IP67
  • Bracket: Stainless Steel
  • Net Weight: 15KG
  • Warranty: 5 Years

FAQ:

1. Are you a factory or trading company:

We are a factory located in Xi'an China, established in 2006.



2. What is your product range?

Our wide product range includes floodlight, street light, pendant light, and power from 60W to 1200W.



3. How many days of production will the order take?

Normally 7-15 days, depending on the order quanity.



4. How do you ship goods abroad?

For sample, trial order, or small quantities we will suggest shipping by air, for large quantity and bulk order we recommend shipping by sea.



5. Does your product support smart control like sensor, dimming, DALI, etc.

They support all of these features, please tell our sales during your negotiation when you need such features.



6. How do you deal with failed lights?

During the warranty period, we will send customer free part or lamp after checking the evidence. After warranty, we only charge the component fees, no extra charge for our customer.
