Place of Origin: | Shaanxi, China |
Brand Name: | Razorlux |
Certification: | ce, EMC, LVD, RoHS, Saa, UL |
Model Number: | RGL2-800P |
Price: | $1,543.00/Pieces |
---|---|
Packaging Details: | 1.EPS Foam+carton(ONE UNIT PER CARTON) <br>2.Carton Size(mm):550*450*560mm<br>3.One 20'' Container can accept 250 Units |
Color Temperature(CCT): | 6000K (Daylight Alert), Cool White | Lamp Luminous Efficiency(lm/w): | 120lm/w |
---|---|---|---|
Color Rendering Index(Ra): | 80 | Working Time (hours): | 50000 |
Product Weight(kg): | 30 | Input Voltage(V): | 80~305Vac,180-528vac |
Beam Angle(°): | 15° 20° 30° | Lamp Body Material: | Aluminum Alloy |
Lamp Luminous Flux(lm): | 96000lm | Working Temperature(℃): | -40 To 60, -40 - 60 |
Warranty: | 5Years | IP Class: | IP 65 (Upgradeable To IP 67) |
High Light: | EMC LED Outdoor Stadium Lighting,96000lm LED Outdoor Stadium Lighting,EMC solar flood lights outdoor |
Features:
1. 80% lumen maintenance over 50,000hours |
2. Wide Power range: 800W |
3. 110-480Vac input voltage without additional adapter |
4. Patent Built-in Serge Protection. |
5. TOP chips high efficacy 120lm/w with meanwell driver |
6. IP67 waterproof, IK10 impact proof |
7. Neutral Salt Spray Resistance |
8. Anti-Corression power coating surface treatment |
9. Stainless steel brackets material.(Upgradable to SS316) |
10. 0-10VDC, DALI and wireless control available |
11. DLC, TUV CE RoHS, CB, SAA, LM79 listed |
12. High uniformity & color rendering index |
Parameters:
Model | RGL-800P | |
Beam Angle | 15° 20° 30° | |
Stable Flux (5700K after 1 hour) |
96000lm | |
Dimension (mm) | 671*405*379 | |
LEDs | 720W | |
Power | Driver | 80W |
Consumption | Total | 800W |
Replace HID Lamp | 1800~2200W | |
Net Weight | 38kg with stainless steel floodlight bracket | |
Color Temperature | 2700-6500K | |
Color Rendering | ≥Ra75 (≥Ra80, ≥Ra90 available on request) | |
Working Life | ≥50000Hrs | |
Housing Material | Aluminum & Powder coating | |
Power Supply | Meanwell | |
IP Class |
IP 65 (Upgradeable to IP 67) |
|
IK Class |
IK 10 |
|
Insulation Class | Class I | |
Working Temperature | -40C ~ 60C / -40F ~ 140F | |
Working Humidity | 10% ~ 95% | |
AC Input | 80-305Vac input voltage without additional adapter | |
DC Input | 100 ~ 400Vdc, 500Vdc ~ 800Vdc | |
THD | <10% | |
Power Factor | ≥0.98 | |
Warranty | LED Module | 5 year |
Driver | 5 year | |
Housing | 10 year |
For Different application requirement, Razorlux Genius Series have different types of beam angles options.
at the moment we have 15° 20° 40° 60° 120° 140° beam angle available.
Application:
Outdoor/Indoor, Stadium, Airport, Marine, Ship, Dock, Trawer, Harour, Mining, Industrial lighting, etc.
Marine: Tugboats, towboats, offshore service vessels, offshore wind platforms and service vessels, ferries, barges, fishing vessels, patrol boats, shipyard cranes, offshore cranes, dredging equipment, shipyard cranes
Commercial Vessels. Suitable for use on tugboats, towboats, passenger ferries, fishing vessels, trawlers and barges.
Advantages:
Razorlux’s reliable in-lighting design and technical team to ensure we deliver as promised
Razorlux continuously improves our range to deliver the best performance, with enhanced operational efficiencies, like:
1. Market-leading weight and sail area = Easy retrofit of old style luminaires, and reduced install costs
2. Meanwell drivers = Ease of maintenance
3. Patented heat sink design = Better heat dissipation in harsh environment
4. Unique design = you can not find the second supplier in the market
5. Wide selection of beam angle = you always find the best one to match with the height of installation
6. Easy installation for electricians = reduced installation costs
7. Full replacement warranty*= confidence that you are working with a company who stands behind their product
8. 0-10V /1-10V dimmable = reduced operating costs and ability to choose what parts of the fields you illuminate
9. Various Colour Temperatures available = easier matching of existing luminaires on site
FAQ:
Q1. Are you a factory?
YES, our factory in XI'AN established in 2010 with 50 workers and 10 engineers.
Q2. : Color temperature of the outdoor led high mast light?
3000/3500/4000/4500/5000/5700/6000/6500K
Q3: Certificates for the outdoor led high mast light?
CE(EMC + LVD) SAA ROHS UL DLC
Q4: How long is the lifetime for the outdoor led high mast light?
50,000HOURS
Q5: Lumens of the outdoor led high mast light?
100-130 LM/W Differs with different series
Q6: Warranty for the outdoor led high mast light?
5 years warranty depends on customers requests
Q7: What lamps can be replaced with the outdoor led high mast light?
Halogen,HPSL & compact fluorescent lamps.
Q8: Any intelligent options for the outdoor led high mast light?
0-10V PWM DALI PLC light control
Q9: Any OEM accessories can be provided when the standard one does not work for installation?
Yes, OEM/ODM support for the different application request.
Q10: Can I have our LOGO on the products and packages?
A: Yes.
Q11: How to deal with the faulty?
Our products are produced in a strict quality control system and the defective rate is less than 0.2%.
If a Quality problem happens, Return/Refund policy according to warranty agreement.
