Place of Origin: | Shaanxi, China |
Brand Name: | Razorlux |
Certification: | ce, LVD, RoHS, Saa |
Model Number: | RGL2-400P |
Price: | $787.00/Pieces |
---|---|
Packaging Details: | 1.EPS Foam+carton(ONE UNIT PER CARTON) <br>2.Carton Size(mm):550*450*560mm<br>3.One 20'' Container can accept 250 Units |
Color Temperature(CCT): | 6000K (Daylight Alert), Cool White | Lamp Luminous Efficiency(lm/w): | 120, 120 |
---|---|---|---|
Color Rendering Index(Ra): | 80 | Working Time (hours): | 50000 |
Product Weight(kg): | 15 | Input Voltage(V): | 80~305Vac,180-528vac |
Beam Angle(°): | 15° 20° 30° | Lamp Body Material: | Aluminum Alloy |
Working Temperature(℃): | -40 To 60, -40 - 60 | Housiong Material: | Aluminum |
IP Class: | IP 65 (Upgradeable To IP 67) | ||
High Light: | 130 Luminous waterproof led flood lights,48000lm waterproof led flood lights,IP67 marine led spotlights |
Razorlux lamps were created for heavy duty work environments. The high quality materials offer superior impact, shock, vibration, UV and corrosion resistance, they are fully sealed against dust and water ingress, making these work lights suitable for the harshest environments and ensuring an ultra long service life. The highly advanced optics ensure that the right amount of light reaches the area it is most needed, with beam patterns designed to generate even illumination and avoid bright spots, dark patches or stray light rays that serve no useful purpose.
Parameters:
1. 80% lumen maintenance over 50,000hours |
2. Wide Power range: 400W |
3. 110-480Vac input voltage without additional adapter |
4. Patent Built-in Serge Protection. |
5. TOP chips high efficacy 120lm/w with meanwell driver |
6. IP67 waterproof, IK10 impact proof |
7. Neutral Salt Spray Resistance |
8. Anti-Corression power coating surface treatment |
9. Stainless steel brackets material.(Upgradable to SS316) |
10. 0-10VDC, DALI and wireless control available |
11. DLC, TUV CE RoHS, CB, SAA, LM79 listed |
12. High uniformity & color rendering index |
Parameters:
Model | RGL2-400P | |
Beam Angle | 15° 20° 30° | |
Stable Flux (5700K after 1 hour) |
48000lm | |
Dimension (mm) | 466*388*487 | |
LEDs | 360W | |
Power | Driver | 40W |
Consumption | Total | 400W |
Replace HID Lamp | 400~600W | |
Net Weight | 19kg with stainless steel floodlight bracket | |
Color Temperature | 2700-6500K | |
Color Rendering | ≥Ra75 (≥Ra80, ≥Ra90 available on request) | |
Working Life | ≥50000Hrs | |
Housing Material | Aluminum & Powder coating | |
Power Supply | Meanwell | |
IP Class |
IP 65 (Upgradeable to IP 67) |
|
IK Class |
IK 10 |
|
Insulation Class | Class I | |
Working Temperature | -40C ~ 60C / -40F ~ 140F | |
Working Humidity | 10% ~ 95% | |
AC Input | 110-480Vac input voltage without additional adapter | |
DC Input | 100 ~ 400Vdc, 500Vdc ~ 800Vdc | |
THD | <10% | |
Power Factor | ≥0.98 | |
Warranty | LED Module | 5 year |
Driver | 5 year | |
Housing | 10 year |
✦ 80% lumen maintenance over 50,000hours.
✦ 110-480Vac input voltage without additional adapter.
✦ 0-10VDC, DALI and wireless control available.
✦ Photocell & motion sensor system available.
✦ Built-in surge protection & thermal protection.
✦ Mercury free, No UV or IR.
✦ High uniformity & color rendering index.
Marine LED Lights are high power flood and high mast lights designed with a specialized corrosion resistant finish that withstands the harsh salt water marine environment. Salt water ocean environments can be incredibly destructive on LED Lighting. These finishes provide a level of assurance and they can withstand these challenging environments for years.
Razorlux continuously improves our range to deliver the best performance, with enhanced operational efficiencies, like:
1.Market-leading weight and sail area = Easy retrofit of old style luminaires, and reduced install costs
2.Meanwell drivers = Ease of maintenance
3.Patented heat sink design = Better heat dissipation in harsh environment
4.Unique design = you can not find the second supplier in the market
5.Wide selection of beam angle = you always find the best one to match with the height of installation
6.Easy installation for electricians = reduced installation costs
7.Full replacement warranty* = confidence that you are working with a company who stands behind their product
8.0-10V /1-10V dimmable = reduced operating costs and ability to choose what parts of the fields you illuminate
9.Various Colour Temperatures available = easier matching of existing luminaires on site
Application:
1. Instead of the fluorescent lights indoors
2. School / Universities / Hospital
3. Conference / Meeting room / Show Room
4. Commercial establishments
5. Factories / Offices
6. Super-markets
FAQ:
Q1. Are you a factory?
YES, our factory in XI'AN established in 2010 with 50 workers and 10 engineers.
Q2. : Color temperature of the outdoor led high mast light?
3000/3500/4000/4500/5000/5700/6000/6500K
Q3: Certificates for the outdoor led high mast light?
CE(EMC + LVD) SAA ROHS UL DLC
Q4: How long is the lifetime for the outdoor led high mast light?
50,000HOURS
Q5: Lumens of the outdoor led high mast light?
100-130 LM/W Differs with different series
Q6: Warranty for the outdoor led high mast light?
5 years warranty depends on customers requests
Q7: What lamps can be replaced with the outdoor led high mast light?
Halogen,HPSL & compact fluorescent lamps.
Q8: Any intelligent options for the outdoor led high mast light?
0-10V PWM DALI PLC light control
Q9: Any OEM accessories can be provided when the standard one does not work for installation?
Yes, OEM/ODM support for the different application request.
Q10: Can I have our LOGO on the products and packages?
A: Yes.
Q11: How to deal with the faulty?
Our products are produced in a strict quality control system and the defective rate is less than 0.2%.
If a Quality problem happens, Return/Refund policy according to warranty agreement.
