Place of Origin: | Shaanxi, China |
Brand Name: | Razorlux |
Certification: | ce, LVD, RoHS, Saa, UL |
Model Number: | RGL2-800P |
Price: | $10.00 - $1,543.00/Pieces |
---|---|
Packaging Details: | 1.EPS Foam+carton(ONE UNIT PER CARTON) <br>2.Carton Size(mm):550*450*560mm<br>3.One 20'' Container can accept 250 Units |
Color Temperature(CCT): | 6000K (Daylight Alert), Cool White | Lamp Luminous Efficiency(lm/w): | 120, 120 |
---|---|---|---|
Color Rendering Index(Ra): | 80 | Lifespan (hours): | 50000 |
Product Weight(kg): | 30 | Input Voltage(V): | 80~305Vac,180-528vac |
Beam Angle(°): | 15° 20° 30° | Lamp Body Material: | Aluminum Alloy |
Light Source: | LED | Lamp Luminous Flux(lm): | 96000lm |
Working Temperature(℃): | -40 To 60, -40 - 60 | IP Class: | IP 65 (Upgradeable To IP 67) |
High Light: | 800W LED Outdoor Flood Light,IP67 LED Outdoor Flood Light,120lm/w high lumen floodlight |
Description:
Marine lighting is mainly used in the offshore oil and gas exploration or production. Marine workers must work, study and rest in a limited space continuously for a long time, and the weather environment is harsh and the working environment is more complicated. Therefore, the lighting design of marine operations is more special and higher Claim. These requirements are closely related to the safety of marine operations and the comfortable and efficient operation of workers on the platform.
Features:
Luminous effect:120lm/w
Control System:DALI Driver,Microwave motion sensor,Photocell Sensor,1-10Vdc Dimming Driver.
Unique design:Multi-function fit in any projects
180 flexible stainaless steel mounting system
Driver:built-in, Meanwell
Universal voltage input 80-305Vac 180-528VAC available on you requests,built in surge protection,built in thermal protection,Led
Module:Osram /Samsung /Lumileds Chip
Waterproof is IP67
Treatment is marine-grade, powder-coated ,die-cast aluminum
High-strength tempered glass mask, high pressure resistance, good light transmission, not easy to break
High-quality aluminum, strong anti-corrosion and anti-rust, fast heat dissipation design
Parameters:
Model | RGL2-800P | |
Beam Angle | 15° 20° 30° | |
Stable Flux (5700K after 1 hour) |
96000lm | |
Dimension (mm) | 671*405*379 | |
LEDs | 720W | |
Power | Driver | 80W |
Consumption | Total | 800W |
Replace HID Lamp | 1800~2200W | |
Net Weight | 38kg with stainless steel floodlight bracket | |
Color Temperature | 2700-6500K | |
Color Rendering | ≥Ra75 (≥Ra80, ≥Ra90 available on request) | |
Working Life | ≥50000Hrs | |
Housing Material | Aluminum & Powder coating | |
Power Supply | Meanwell | |
IP Class |
IP 65 (Upgradeable to IP 67) |
|
IK Class |
IK 10 |
|
Insulation Class | Class I | |
Working Temperature | -40C ~ 60C / -40F ~ 140F | |
Working Humidity | 10% ~ 95% | |
AC Input | 80-305Vac input voltage without additional adapter | |
DC Input | 100 ~ 400Vdc, 500Vdc ~ 800Vdc | |
THD | <10% | |
Power Factor | ≥0.98 | |
Warranty | LED Module | 5 year |
Driver | 5 year | |
Housing | 10 year |
For Different application requirement, Razorlux Genius Series have different types of beam angles options.
at the moment we have 15° 20° 30° 40° 60° 120° 140° beam angle available.
Advantage:
120LM/W OPTIMAL EFFICIENCY
5000K daylight LED flood light perfectly replaced the standard 2000-Watt incandescent bulbs. Save 87% of your electricity bill.
180° ADJUSTABLE MOUNT
Equipped with 180° adjustable knuckle mount, allow you to adjust the angle of this outdoor led spot light to get a wider beam angle.
WIDE APPLICATIONS
Light up stadium, ship, building, Court, as well as LED security light in warehouse, workshop etc. Suitable for use in both indoor and outdoor applications.
LONG LIFESPAN
50,000 hours lifespan which means if it works 8 hours per day, it can work more than 17 years. IP67Waterproof makes it ideal for outdoor and indoor use.
Application:
Commercial Vessels. Suitable for use on tugboats, towboats, passenger ferries, fishing vessels, trawlers and barges.
Marine applications: Walkways, doorways and stairwells on the deck and interior of vessels, as well as perimeter deck lighting
Mining applications: Perimeter and walkway lighting on large mining equipment like shovels and draglines, machine, electrical and engine rooms, as well as any dusty or dirty location.
Industrial: Parking garages, carwashes, transportation centers, subways, swimming pools, locker rooms, automotive repair facilities as well as food processing facilities, including walk-in freezers, and industrial kitchens
FAQ:
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
