Place of Origin: | Shaanxi, China |
Brand Name: | Razorlux |
Certification: | ce, C-tick, EMC, LVD, RoHS, Saa, UL |
Model Number: | RGL2-300A |
Price: | $400.00 - $530.00/Pieces |
---|---|
Packaging Details: | 1.EPS Foam+carton(ONE UNIT PER CARTON) <br>2.Carton Size(mm):550*450*415mm<br>3.One 20'' Container can accept 250 Units |
Color Temperature(CCT): | 5000K (Daylight) | Lamp Luminous Efficiency(lm/w): | 125 |
---|---|---|---|
Lifespan (hours): | 50000 | Product Weight(kg): | 15 |
Input Voltage(V): | 80~305Vac,180-528vac | Beam Angle(°): | 40° 60° 120° 140° |
IP Rating: | IP67 | Working Temperature(℃): | -40 To 60 |
LED Driver: | Meanwell | Housing Material: | Die-cast Aluminum Alloy |
Painting: | Powder Coating | IK Rate: | IK10 |
High Light: | CCT Marine Led Flood Light,300W Marine Led Flood Light,5000K boat deck lights led |
Features:
Luminous effect:120lm/w
Control System:DALI Driver,Microwave motion sensor,Photocell Sensor,1-10Vdc Dimming Driver.
Unique design:Multi-function fit in any projects
180 flexible stainaless steel mounting system
Driver:built-in, Meanwell
Universal voltage input 80-305Vac 180-528VAC available on you requests,built in surge protection,built in thermal protection,Led
Module:Osram /Samsung /Lumileds Chip
Waterproof is IP67
Treatment is marine-grade, powder-coated ,die-cast aluminum
Parameters:
Model | RGL2-300A | |
Beam Angle | 40° 60° 120° 140° | |
Stable Flux (5700K after 1 hour) |
39000lm | |
Dimension (mm) | 468*388*367 | |
LEDs | 270W | |
Power | Driver | 30W |
Consumption | Total | 300W |
Replace HID Lamp | 600~800W | |
Net Weight | 17.9kg with stainless steel floodlight bracket | |
Color Temperature | 2700-6500K | |
Color Rendering | ≥Ra75 (≥Ra80, ≥Ra90 available on request) | |
Working Life | ≥50000Hrs | |
Housing Material | Aluminum & Powder coating | |
Power Supply | Meanwell | |
IP Class |
IP 65 (Upgradeable to IP 67) |
|
IK Class |
IK 10 |
|
Insulation Class | Class I | |
Working Temperature | -40C ~ 60C / -40F ~ 140F | |
Working Humidity | 10% ~ 95% | |
AC Input | 110-480Vac input voltage without additional adapter | |
DC Input | 100 ~ 400Vdc, 500Vdc ~ 800Vdc | |
THD | <10% | |
Power Factor | ≥0.98 | |
Warranty | LED Module | 5 year |
Driver | 5 year | |
Housing | 10 year |
For Different application requirement, Razorlux Genius Series have different types of beam angles options.
at the moment we have 15° 20° 40° 60° 120° 140° beam angle available.
Application:
Outdoor/Indoor, Stadium, Airport, Marine, Ship, Dock, Trawer, Harour, Mining, Industrial lighting, etc.
Marine: Tugboats, towboats, offshore service vessels, offshore wind platforms and service vessels, ferries, barges, fishing vessels, patrol boats, shipyard cranes, offshore cranes, dredging equipment, shipyard cranes
Commercial Vessels. Suitable for use on tugboats, towboats, passenger ferries, fishing vessels, trawlers and barges.
Marine applications: Walkways, doorways and stairwells on the deck and interior of vessels, as well as perimeter deck lighting
Mining applications: Perimeter and walkway lighting on large mining equipment like shovels and draglines, machine, electrical and engine rooms, as well as any dusty or dirty location
Industrial: Parking garages, carwashes, transportation centers, subways, swimming pools, locker rooms, automotive repair facilities as well as food processing facilities, including walk-in freezers, and industrial kitchens
FAQ:
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
