Place of Origin: | Shaanxi, China |
Brand Name: | Razorlux |
Certification: | ce, LVD, RoHS, Saa |
Model Number: | RGL2-400P |
Price: | $787.00/Pieces |
---|---|
Packaging Details: | 1.EPS Foam+carton(ONE UNIT PER CARTON) <br>2.Carton Size(mm):550*450*560mm<br>3.One 20'' Container can accept 250 Units |
Color Temperature(CCT): | 2700-6500K, Cool White | Color Rendering Index(Ra): | 75 |
---|---|---|---|
Lighting Solutions Service: | Lighting And Circuitry Design, DIALux Evo Layout | Lifespan (hours): | 50000 |
Input Voltage(V): | 80~305Vac,180-528vac | Beam Angle(°): | 15° 20° 30° |
Lamp Body Material: | Aluminum Alloy | Lamp Luminous Flux(lm): | 48000lm |
Working Temperature(℃): | -40 - 60, -40 - 60 | Warranty(Year): | 5-Year |
Lamp Luminous Efficiency(lm/w): | 120 | IP Class: | IP 65 (Upgradeable To IP 67) |
High Light: | 120lm/w led boat flood lights,75Ra led boat flood lights,lumitec spreader lights |
5 Years Warranty IP67 Waterproof Stadium Garden Boats flood led light outdoor
Features:
80% lumen maintenance over 50,000hours.
110-480Vac input voltage without additional adapter.
0-10VDC, DALI and wireless control available.
Photocell & motion sensor system available.
Built-in surge protection & thermal protection.
Mercury free, No UV or IR.
High uniformity & color rendering index.
Parameters
Model
|
|
RGL2-400P
|
|
Beam Angle
|
|
15° 20° 30°
|
|
Stable Flux (5700K after 1 hour)
|
|
48000lm
|
|
Dimension (mm)
|
|
466*388*487
|
|
Consumption |
LEDs
|
360W
|
|
Power
|
Driver
|
40W
|
|
Consumption
|
Total
|
400W
|
|
Replace HID Lamp
|
|
800~1000W
|
|
Net Weight
|
|
19kg (42lbs)
|
|
Color Temperature
|
|
2700-6500K
|
|
Color Rendering
|
|
≥Ra75 (≥Ra80, ≥Ra90 available on request)
|
|
Working Life
|
|
≥50000Hrs
|
|
Housing Material
|
|
Aluminum & Powder coating
|
|
Power Supply
|
|
Meanwell
|
|
IP Class
|
|
IP 65 (Upgradeable to IP 67)
|
|
IK Class
|
|
IK 10
|
|
Insulation Class
|
|
Class I
|
|
Working Temperature
|
|
-40C ~ 60C / -40F ~ 140F
|
|
Working Humidity
|
|
10% ~ 95%
|
|
AC Input
|
|
110-480Vac input voltage without additional adapter
|
|
DC Input
|
|
100 ~ 400Vdc, 500Vdc ~ 800Vdc
|
|
THD
|
|
<10%
|
|
Power Factor
|
|
≥0.98
|
|
Warranty
|
LED Module
|
5 years
|
|
|
Driver
|
5 years
|
|
|
Housing
|
10 years
|
Advantage:
2. Universival input without additional.
3. Meanwell driver,heat resistant for our power supply. It can working well on temperature at 55°C
4. Multi-function designed, flexible,you always find a combination fitting your projects perfectly.
5. Unique and elegant appearance,and patented heat dissipation technology.
6. Have cooperated with a lot of importers in EU markets more than 10 years.
7. Experienced in doing business with big customers.
8. Own designing team for new products development ,our products were developed by ourselves and we hold 125 patents.
9. We have passed the testing and got the ISO9001,TUV,LVD,SAA,CE,UL,DLC,CUL,Rohs certificates.
10. Different lens,reflectors ,and accessories,they can be varied beam angle mounting bracket,control system and etc.
Application:
Outdoor/Indoor, Stadium, Airport, Marine, Ship, Dock, Trawer, Harour, Mining, Industrial lighting, etc.
FAQ:
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
