Place of Origin: | Shaanxi, China |
Brand Name: | Razorlux |
Certification: | ce, LVD, RoHS, Saa, UL |
Model Number: | RGL2-500A |
Price: | $510.00 - $630.00/Pieces |
---|---|
Packaging Details: | 1.EPS Foam+carton(ONE UNIT PER CARTON) <br>2.Carton Size(mm):550*450*415mm<br>3.One 20'' Container can accept 250 Units |
Supply Ability: | 5000 Piece/Pieces per Month |
Color Temperature(CCT): | 2700-6500K, Cool White | Lamp Luminous Efficiency(lm/w): | 130LM/W |
---|---|---|---|
Color Rendering Index(Ra): | 75 | Lighting Solutions Service: | Lighting And Circuitry Design, DIALux Evo Layout |
Input Voltage(V): | 80~305Vac,180-528vac | Beam Angle(°): | 40° 60° 120° 140° |
Working Lifetime(Hour): | 50000 | Lamp Luminous Flux(lm): | 65000lm |
Working Temperature(℃): | -40C~60C/40F~140F | Warranty(Year): | 5-Year |
Housiong Material: | Aluminum & Powder Coating | IP Class: | IP 65 (Upgradeable To IP 67) |
High Light: | Aluminum Alloy dimmable led flood lights,500 watt dimmable led flood lights,6500K outdoor flood light fixtures waterproof |
Model
|
|
RGL2-500A
|
|
Beam Angle
|
|
40° 60° 120° 140°
|
|
Stable Flux (5700K after 1 hour)
|
|
65000lm
|
|
Dimension (mm)
|
|
468*388*367
|
|
Power Consumption |
LEDs
|
450W
|
|
|
Driver
|
50W
|
|
|
Total
|
500W
|
|
Replace HID Lamp
|
|
1000~1200W
|
|
Net Weight
|
|
15kg (33lbs)
|
|
Color Temperature
|
|
2700-6500K
|
|
Color Rendering
|
|
≥Ra75
|
|
Working Life
|
|
≥50000Hrs
|
|
Housing Material
|
|
Aluminum & Powder coating
|
|
IP Class
|
|
IP67
|
|
Power Supply
|
|
Meanwell
|
|
Working Temperature
|
|
-40C ~ 60C / -40F ~ 140F
|
|
AC Input
|
|
80~315Vac, (347Vac available on request)
|
|
Power Factor
|
|
≥0.98
|
|
Warranty
|
|
5 years
|
Features:
For your yacht or your yard.
For your dock or your deck.
Die-cast aluminum alloy housing.
Marine-grade white powder-coated finish.
Rugged and with an ample heat sink to the LEDs to ensure long-life operation.
Multi-voltage 12VDC or 24VDC (10-30VDC) or 12VAC.
Works on most low-voltage outdoor lighting systems.
Instant-on, no warm-up of bulb needed.
Long service life.
Modern styling and compact design.
Shock-resistant, ultra-rugged with no filament to burn out or break.
Application:
Marine: Tugboats, towboats, offshore service vessels, offshore wind platforms and service vessels, ferries, barges, fishing vessels, patrol boats, shipyard cranes, offshore cranes, dredging equipment, shipyard cranes
Commercial Vessels. Suitable for use on tugboats, towboats, passenger ferries, fishing vessels, trawlers and barges.
Marine applications: Walkways, doorways and stairwells on the deck and interior of vessels, as well as perimeter deck lighting
Advantages:
Razorlux’s reliable in-lighting design and technical team to ensure we deliver as promised
Razorlux continuously improves our range to deliver the best performance, with enhanced operational efficiencies, like:
1. Market-leading weight and sail area = Easy retrofit of old style luminaires, and reduced install costs
2. Meanwell drivers = Ease of maintenance
3. Patented heat sink design = Better heat dissipation in harsh environment
4. Unique design = you can not find the second supplier in the market
5. Wide selection of beam angle = you always find the best one to match with the height of installation
6. Easy installation for electricians = reduced installation costs
7. Full replacement warranty* = confidence that you are working with a company who stands behind their product
8. 0-10V /1-10V dimmable = reduced operating costs and ability to choose what parts of the fields you illuminate
9. Various Colour Temperatures available = easier matching of existing luminaires on site
FAQ:
Q1. Are you a factory?
YES, our factory in XI'AN established in 2010 with 50 workers and 10 engineers.
Q2. : Color temperature of the outdoor led high mast light?
3000/3500/4000/4500/5000/5700/6000/6500K
Q3: Certificates for the outdoor led high mast light?
CE(EMC + LVD) SAA ROHS UL DLC
Q4: How long is the lifetime for the outdoor led high mast light?
50,000HOURS
Q5: Lumens of the outdoor led high mast light?
100-130 LM/W Differs with different series
Q6: Warranty for the outdoor led high mast light?
5 years warranty depends on customers requests
Q7: What lamps can be replaced with the outdoor led high mast light?
Halogen,HPSL & compact fluorescent lamps.
Q8: Any intelligent options for the outdoor led high mast light?
0-10V PWM DALI PLC light control
Q9: Any OEM accessories can be provided when the standard one does not work for installation?
Yes, OEM/ODM support for the different application request.
Q10: Can I have our LOGO on the products and packages?
A: Yes.
Q11: How to deal with the faulty?
Our products are produced in a strict quality control system and the defective rate is less than 0.2%.
If a Quality problem happens, Return/Refund policy according to warranty agreement.
