Place of Origin: | Shaanxi, China |
Brand Name: | Razorlux |
Certification: | ce, LVD, RoHS, Saa, UL |
Model Number: | RGL2-1000A |
Price: | $1,600.00/Pieces |
---|---|
Packaging Details: | 1.EPS Foam+carton(ONE UNIT PER CARTON) <br>2.Carton Size(mm):550*450*415mm<br>3.One 20'' Container can accept 250 Units |
Lamp Luminous Efficiency(lm/w): | 130LM/W | Color Rendering Index(Ra): | 75 |
---|---|---|---|
Lifespan (hours): | 50000 | Input Voltage(V): | 80~305Vac,180-528vac |
Beam Angle(°): | 40° 60° 120° 140° | Working Temperature(℃): | -40 - 60, -40 - 60 |
Housiong Material: | Aluminum | IP Class: | IP 65 (Upgradeable To IP 67) |
Color Temperature: | 2700-6500K | Luminous Efficacy(lm/w): | 130 |
High Light: | 1000w Boat Flood Lights,Narrow Beam Angle Marine Floodlight,LED Boat Deck Flood Lights |
Lighter & Thinner Featuring with corrosion proof casting aluminum heat sink & sleek shatter-proof tempered glass diffuser, Razolux provides a more aesthetic pleasing feeling and blends perfectly into all exteriors. Unique reflector Multiple Beam Angles deliver more lumens to the desired target. It will siginificantly enhance the visibility of lighting area and improve safety, or help the views more bright and beautiful. Highly energy efficient 130lm/W, super durable and high performance, Razorlux is energy efficient as well as cost efficient.
Lighter & Thinner Featuring with corrosion proof casting aluminum heat sink & sleek shatter-proof tempered glass diffuser, Razorlux provides a more aesthetic pleasing feeling and blends perfectly into all exteriors. Unique reflector Multiple Beam Angles deliver more lumens to the desired target. It will siginificantly enhance the visibility of lighting area and improve safety, or help the views more bright and beautiful. Highly energy efficient 130lm/W, super durable and high performance, Razorlux is energy efficient as well as cost efficient.
Razorlux is a product development company solely focused on the conceptualization, development, and manufacture of extreme environment LED lighting. harsh environment, fish industry, Proudly manufacturing in CHINA, the RAZORLUX team possesses a deep understanding of thermal, optical, and electromechanical principles which allows us to offer exceptional performance, quality and reliability to the markets and customers we serve.
Model
|
|
RGL-1000A
|
|
Beam Angle
|
|
40° 60° 120° 140°
|
|
Stable Flux (5700K after 1 hour)
|
|
130000lm
|
|
Dimension (mm)
|
|
671*405*379
|
|
Power Consumption |
LEDs
|
900W
|
|
|
Driver
|
100W
|
|
|
Total
|
1000W
|
|
Replace HID Lamp
|
|
2200~2500W
|
|
Net Weight
|
|
30kg (66lbs)
|
|
Color Temperature
|
|
2700-6500K
|
|
Color Rendering
|
|
≥Ra75 (≥Ra80, ≥Ra90 available on request)
|
|
Working Life
|
|
≥50000Hrs
|
|
Housing Material
|
|
Aluminum & Powder coating
|
|
Power Supply
|
|
Meanwell
|
|
IP Class
|
|
IP 65 (Upgradeable to IP 67)
|
|
IK Class
|
|
IK 10
|
|
Insulation Class
|
|
Class I
|
|
Working Temperature
|
|
-40C ~ 60C / -40F ~ 140F
|
|
Working Humidity
|
|
10% ~ 95%
|
|
AC Input
|
|
80~305Vac
|
|
DC Input
|
|
100 ~ 400Vdc, 500Vdc ~ 800Vdc
|
|
THD
|
|
<10%
|
|
Power Factor
|
|
≥0.98
|
|
Warranty
|
LED Module
|
5 years
|
|
|
Driver
|
5 years
|
|
|
Housing
|
10 years
|
Razorlux Genius Series lights powder coating is designed for the exterior environment offering excellent long term light and weather resistance. Its marine grade anti-corrosive coating has passed multiple chemical and durability tests including: Salt Spray tests
Luminous effect:130lm/w
Control System:DALI Driver,Microwave motion sensor,Photocell Sensor,1-10Vdc Dimming Driver.
Unique design:Multi-function fit in any projects
180 flexible stainaless steel mounting system
Driver:built-in, Meanwell
Universal voltage input 80-305Vac 180-528VAC available on you requests,built in surge protection,built in thermal protection,Led
Module:Osram /Samsung /Lumileds Chip
Waterproof is IP67
Treatment is marine-grade, powder-coated ,die-cast aluminum
High-strength tempered glass mask, high pressure resistance, good light transmission, not easy to break
High-quality aluminum, strong anti-corrosion and anti-rust, fast heat dissipation design
FAQ:
Q1. Are you a factory?
YES, our factory in XI'AN established in 2010 with 50 workers and 10 engineers.
Q2. : Color temperature of the outdoor led high mast light?
3000/3500/4000/4500/5000/5700/6000/6500K
Q3: Certificates for the outdoor led high mast light?
CE(EMC + LVD) SAA ROHS UL DLC
Q4: How long is the lifetime for the outdoor led high mast light?
50,000HOURS
Q5: Lumens of the outdoor led high mast light?
100-130 LM/W Differs with different series
Q6: Warranty for the outdoor led high mast light?
5 years warranty depends on customers requests
Q7: What lamps can be replaced with the outdoor led high mast light?
Halogen,HPSL & compact fluorescent lamps.
Q8: Any intelligent options for the outdoor led high mast light?
0-10V PWM DALI PLC light control
Q9: Any OEM accessories can be provided when the standard one does not work for installation?
Yes, OEM/ODM support for the different application request.
Q10: Can I have our LOGO on the products and packages?
A: Yes.
Q11: How to deal with the faulty?
Our products are produced in a strict quality control system and the defective rate is less than 0.2%.f a Quality problem happens, Return/Refund policy according to warranty agreement.
