Aluminum Alloy IP67 LED Navigation Lights For Marine Boating

Aluminum Alloy IP67 LED Navigation Lights For Marine Boating

  • Aluminum Alloy IP67 LED Navigation Lights For Marine Boating
  • Aluminum Alloy IP67 LED Navigation Lights For Marine Boating
  • Aluminum Alloy IP67 LED Navigation Lights For Marine Boating
Aluminum Alloy IP67 LED Navigation Lights For Marine Boating
Product Details:
Place of Origin: Shaanxi, China
Brand Name: Razorlux
Certification: ce, LVD, RoHS, Saa, UL
Model Number: RGL2-300A
Payment & Shipping Terms:
Price: $455.00/Pieces >=1 Pieces
Packaging Details: 1.EPS Foam+carton(ONE UNIT PER CARTON) <br>2.Carton Size(mm):550*450*415mm <br>3.One 20'' Container can accept 250 Units
Supply Ability: 3000 Piece/Pieces per Month
Contact Now
Detailed Product Description
Color Temperature(CCT): 2700-6500K, Cool White Lamp Luminous Efficiency(lm/w): 130LM/W
Color Rendering Index(Ra): 75 Working Time (hours): 50000
Input Voltage(V): 80~305Vac,180-528vac Beam Angle(°): 40° 60° 120° 140°
Working Lifetime(Hour): 50000 Lamp Body Material: Aluminum Alloy
Lamp Luminous Flux(lm): 39000LM Working Temperature(℃): -40C~60C/40F~140F
Product Name: Floodlight 200W IP Class: IP 65 (Upgradeable To IP 67)
Luminous Efficacy(lm/w): 130
High Light:

IP67 LED Navigation Lights

,

Navigation Boat Flood Lights

,

Aluminum Alloy LED Boat Flood Lights

2022 IP67 Marine Boating's Best LED Navigation Lights

Parameters:

Model

RGL2-300A
Beam Angle

40° 60° 120° 140°
Stable Flux (5700K after 1 hour)

39000lm
Dimension (mm)

468*388*367

Power Consumption
LEDs
270W

Driver
30W

Total
300W
Replace HID Lamp

400~600W
Net Weight

15kg (33lbs)
Color Temperature

2700-6500K
Color Rendering

≥Ra75 (≥Ra80, ≥Ra90 available on request)
Working Life

≥50000Hrs
Housing Material

Aluminum & Powder coating
Power Supply

Meanwell
IP Class

IP 65 (Upgradeable to IP 67)
IK Class

IK 10
Insulation Class

Class I
Working Temperature

-40C ~ 60C / -40F ~ 140F
Working Humidity

10% ~ 95%
AC Input

110-480Vac input voltage without additional adapter
DC Input

100 ~ 400Vdc, 500Vdc ~ 800Vdc
THD

<10%
Power Factor

≥0.98

    Warranty
LED Module
5 years

Driver
5 years

Housing
10 years



Features:
1. 80% lumen maintenance over 50000hours.
2. Wide Power range: 400W.
3. 110-480Vac input voltage without additional adapter.
4. Patent Built-in Serge Protection.
5. Top chips high efficacy 120lm/w with meanwell driver.
6. IP67 waterproof, IK10 impact proof.
7. NeutralSalt Spray Resistance.
8. Anti-Corression power coating surface treatment.
9. Stainless steel brackets material.(Upgradable to SS316)
10. 0-10VDC, DALI and wireless control available.
11. UL cUL DLC, TUV CE RoHS, CB, SAA, LM79 listed.

12. High uniformity & color rendering index.



Application:



Aluminum Alloy IP67 LED Navigation Lights For Marine Boating 0



Outdoor/Indoor, Stadium, Airport, Marine, Ship, Dock, Trawer, Harour, Mining, Industrial lighting, etc.



Marine applications: Walkways, doorways and stairwells on the deck and interior of vessels, as well as perimeter deck lighting



Mining applications: Perimeter and walkway lighting on large mining equipment like shovels and draglines, machine, electrical and engine rooms, as well as any dusty or dirty location



Industrial: Parking garages, carwashes, transportation centers, subways, swimming pools, locker rooms, automotive repair facilities as well as food processing facilities, including walk-in freezers, and industrial kitchens



Description:



Razorlux Genius Series lights powder coating is designed for the exterior environment offering excellent long term light and weather resistance. Its marine grade anti-corrosive coating has passed multiple chemical and durability tests including: Salt Spray tests





Razorlux is a product development company solely focused on the conceptualization, development, and manufacture of extreme environment LED lighting. harsh environment, fish industry, Proudly manufacturing in CHINA, the RAZORLUX team possesses a deep understanding of thermal, optical, and electromechanical principles which allows us to offer exceptional performance, quality and reliability to the markets and customers we serve.



Advantage:



  • BETTER DESIGN - Designed for higher installations above 25ft, these lights push more light to the ground.
  • 15,20,30,60,120,140 degree beam angle pushes more of the light to the ground. Ideal for higher installs and designed to replace a 500 watt Metal Halide. Photometric studies available. This LED Stadium light or LED Arena Light only uses Premium Grade LED components.
  • SURGE PROTECTION - Separate 10KV surge protection device to avoid early failure due to power surge.
  • BRIGHT LIGHT - 500 Watt LED puts out 66,500 Lumens and can replace a 1500 watt Metal halide MH or HPS/HID light. 400 Watt LED puts out 66,500 Lumens and can replace a 1000 watt Metal halide MH or HPS/HID light. 5000K light color ensures a bright clear light.
  • DIMMABLE - 0-10v Dimmable Top- provides high reliability plus optional dimming.
  • EASY ADJUSTABLE MOUNT - Unit comes with an adjustable mount designed to fit on in multiple ways. The light can be angled up or down depending to focus the action. Optional Slip-Fit Mount makes install a breeze with the use of a wide variety of tenon adapters. Ideal for aiming your light in the right direction or lighting farther away areas. Great light for sports courts such as Basketball, Tennis, Soccer etc, etc. Highly versatile light.
  • BUILT TO LAST - 150,000hr LEDs saves having to replace bulbs. Aluminum Housing with high tech Heat Sink. Better Heat dissipation ensures longer LED life and safety. IP65 Waterproof for all weather conditions. All backed by a 5year warranty and our Customer Support Team.

FAQ:



Q1. Can I have a sample order for led light?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.



Q2. What about the lead time?

A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than



Q3. Do you have any MOQ limit for led light order?

A: Low MOQ, 1pc for sample checking is available



Q4. How do you ship the goods and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.



Q5. How to proceed an order for led light?

A: Firstly let us know your requirements or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms the samples and places deposit for formal order.

Fourthly We arrange the production.



Q6. Is it OK to print my logo on led light product?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.



Q7: Do you offer guarantee for the products?

A: Yes, we offer 2-5 years warranty to our products.



Q8: How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.

Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
