200W Effective Control Dimmable LED lamp
Features
✦ 80% lumen maintenance over 50,000hours
✦ 90-305VAC input voltage without additional adapter
✦ 0-10VDC, DALI and wireless control available
✦ Photocell & motion sensor system available
✦ Built-in surge protection & thermal protection
✦ Maintenance free
✦ Mercury free, No UV or IR
Discription
LED lights are a great solution for saving energy, but you can even go one step further. LED lights can be dimmed without using any excess energy. Adjusting the dimmer does not waste energy the way traditional incandescent or fluorescent bulbs would when switching them on and off. With LEDs,
Parameters
| Model |
RGL-200F |
| Beam Angle |
5°,10°,8X48° |
|
Stable Flux
(5700K after 1 hour)
|
22000 lm |
| Dimension (mm) |
360X358X192mm |
| |
LEDs |
180W |
| Power |
Driver |
20W |
| Consumption |
Total |
200W |
| Replace HID Lamp |
400-600W |
| Net Weight |
15kg |
| Color Temperature |
2000K - 6000K |
| Color Rendering |
≥Ra75 (≥Ra80, ≥Ra90 available on request) |
| Working Life |
≥50000Hrs |
| Housing Material |
Aluminum |
| Coating |
Powder Coating |
| IP Class |
IP 65 (Upgradeable to IP 67) |
| IK Class |
IK 10 |
| Insulation Class |
Class I |
| Working Temperature |
-40C ~ 55C |
| Working Humidity |
10% ~ 95% |
| AC Input |
90V-305VAC 47-63 Hz |
| THD |
<10% |
| Power Factor |
≥0.98 |
| Warranty |
LED Module |
5 years |
| Driver |
5 years |
| Housing |
10 years |
Application:
Street | Bridge | Marine | Stadium |Billboard | Wall Light | Factory |Shopping Mall | Petrol Station |
Conference Centers | Cold Storage | Floodlighting | Tower Crane
Advantages:
1.Service:We also provide our client with lighting layout design and brightness calculation of projects ,Razorlux would be your first choice of professional Led lighting supplies.
2.Universival input without additional.
3.Meanwell driver,heat resistant for our power supply,It can working well on temperature at 55°C
4.Multi-function designed, flexible,you always find a combination fitting your projects perfectly.
5.Unique and elegant appearance,and patented heat dissipation technology.
FAQ:
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
