Outdoor Street High Mast Led Flood Light 10800 Lm 90w Sports Stadiums

Outdoor Street High Mast Led Flood Light 10800 Lm 90w Sports Stadiums

  • Outdoor Street High Mast Led Flood Light 10800 Lm 90w Sports Stadiums
  • Outdoor Street High Mast Led Flood Light 10800 Lm 90w Sports Stadiums
  • Outdoor Street High Mast Led Flood Light 10800 Lm 90w Sports Stadiums
  • Outdoor Street High Mast Led Flood Light 10800 Lm 90w Sports Stadiums
Outdoor Street High Mast Led Flood Light 10800 Lm 90w Sports Stadiums
Product Details:
Place of Origin: Shaanxi, China
Brand Name: Razorlux
Certification: ce, LVD, Saa, UL
Model Number: RGL-90A
Payment & Shipping Terms:
Price: $170.00/Pieces >=1 Pieces
Packaging Details: 1.EPS Foam+carton(ONE UNIT PER CARTON) <br>2.Carton Size(mm):263*263*155 <br>3.One 20'' Container can accept 250 Units
Supply Ability: 5000 Piece/Pieces per Month
Contact Now
Detailed Product Description
Color Temperature(CCT): 2000K - 6000K, Cool White Lamp Luminous Efficiency(lm/w): 120lm/w
Color Rendering Index(Ra): 80 Lighting Solutions Service: Lighting And Circuitry Design, DIALux Evo Layout
Lifespan (hours): 50000 Input Voltage(V): 80 ~ 305Vac
Beam Angle(°): 60°/120°/140°x60° Lamp Body Material: Aluminum
Application: Sports Stadiums, Street/stadium/Ship/outdoor Lighting Lamp Luminous Flux(lm): 10800 Lm
Working Temperature(℃): -40C ~ 60C / -40F ~ 140F Warranty(Year): 5-Year
Power: 90w
High Light:

10800 lm high mast led flood light

,

90w high mast led flood light

,

6000K Outdoor led street light


Outdoor lighting stadium marine street light 90w led high mast flood lights for high pole

Model

RGL-90A
Beam Angle

60°/120°/140°x60°
Stable Flux (5700K after 1 hour)

10800 lm
Dimension (mm)

360x358x187mm

Power Consumption
LEDs
81W
Power
Driver
9W
Consumption
Total
90W
Replace HID Lamp

150-250W
Net Weight

8kg (17.6lbs)
Color Temperature

2000K - 6000K
Color Rendering

≥Ra80
Working Life

≥50000Hrs
Housing Material

Aluminum
Coating

Zinc Rich Paint
IP Class

IP 65 (Upgradeable to IP 67)
Insulation Class

Class I (Upgradeable to Class II)
Working Temperature

-40C ~ 60C / -40F ~ 140F
Working Humidity

10% ~ 95%
AC Input

80 ~ 315Vac, (347Vac available on request)
DC Input

80 ~ 400Vdc, (12Vdc, 24Vdc and other input available on request)
THD

<10%
Power Factor

≥0.98

Warranty
LED Module
5 years

Driver
5 years

Housing
10 years



Application:



Outdoor Street High Mast Led Flood Light 10800 Lm 90w Sports Stadiums 1



Outdoor Street High Mast Led Flood Light 10800 Lm 90w Sports Stadiums 2



Industrial: Parking garages, carwashes, transportation centers, subways, swimming pools, locker rooms, automotive repair facilities as well as food processing facilities, including walk-in freezers, and industrial kitchens.



Features:

80-305Vac,12-24V DC Voltage Range

Commercial marine grade powder-coating and treatment on a die-cast aluminum housing

316 Stainless steel mounting bracket and fastening components

IP67 for protection from the elements and maintenance-free operation

2700K-6000K,5000K Daylight White color, perfect for work areas

LEDs with a 15,°20°,40°, 60°120°,beam angle

IP67 waterproof, IK10 impact proof

TOP chips high efficacy 130lm/w±7% with meanwell driver

0-10VDC, Casambi,DALI and wireless control available

DLC, TUV CE RoHS, CB, SAA, UL,LM79 listed

Neutral Salt Spray Resistance



Advantage:



High Output and Energy-Efficient: The Razorlux 400W LED floodlight provides 48000umens of 5000K daylight white light, equivalent to the 1000W MH/HPS, thereby slashing the utility bills by 60% instantly.



CE UL Listed: We can vouch for the quality of our top-notch products and remove the risk attached to ensure 100% customer satisfaction. With a sturdy and durable casing, they have a tested lifespan of 15,000 hours. they work five hours per day providing reliable radiant light for eight years or more. The 400W outdoor LED flood lights will not degrade over time, thanks to the superior quality of the heavy-duty casing. We highly recommend replacing your existing lights with our fantastic light fixtures to save your valuable time, money, and energy.



Waterproof IP65 Rating: Tested and verified with the backing of the IP65 certification, these flood lights endure extreme outdoor weather conditions, are water-resistant, and offer excellent corrosion resistance. They are used both for commercial and residential purposes in probable areas like yards, pools, parking areas, gardens, driveways, playgrounds, and the like.



Built to Last: These state-of-the-art lights, furnished with the latest LED technology, have commercial-grade die-cast aluminum housing that ensures maximum luminous performance, and the heavy-gauge heat dissipation structure increases heat dissipation capacity. The impact-resistant tempered glass lens offers an anti-glare diffuser.



Fully Adjustable, Directional, Flexible to Use: Equipped with a 180-degree adjustable yoke-style bracket mounting arm, the Razolux 400W LED security lights may be flexibly positioned at any angle and can be easily wall-mounted, horizontally mounted under an eave or secured to the ground for accentuating large landscape area.





FAQ:



Q1. Are you a factory?
YES, our factory in XI'AN established in 2010 with 50 workers and 10 engineers.

Q2. : Color temperature of the outdoor led high mast light?
3000/3500/4000/4500/5000/5700/6000/6500K

Q3: Certificates for the outdoor led high mast light?
CE(EMC + LVD) SAA ROHS UL DLC

Q4: How long is the lifetime for the outdoor led high mast light?
50,000HOURS

Q5: Lumens of the outdoor led high mast light?
100-130 LM/W Differs with different series

Q6: Warranty for the outdoor led high mast light?
5 years warranty depends on customers requests

Q7: What lamps can be replaced with the outdoor led high mast light?
Halogen,HPSL & compact fluorescent lamps.

Q8: Any intelligent options for the outdoor led high mast light?
0-10V PWM DALI PLC light control

Q9: Any OEM accessories can be provided when the standard one does not work for installation?
Yes, OEM/ODM support for the different application request.

Q10: Can I have our LOGO on the products and packages?
A: Yes.

Q11: How to deal with the faulty?
Our products are produced in a strict quality control system and the defective rate is less than 0.2%.
If a Quality problem happens, Return/Refund policy according to warranty agreement.
