Place of Origin: | Shaanxi, China |
Brand Name: | Razorlux |
Certification: | ce, LVD, RoHS, Saa, UL |
Model Number: | RGL2-1000A |
Price: | $1,600.00/Pieces |
---|---|
Packaging Details: | 1.EPS Foam+carton(ONE UNIT PER CARTON) <br>2.Carton Size(mm):550*450*415mm<br>3.One 20'' Container can accept 250 Units |
Lighting Solutions Service: | Lighting And Circuitry Design, Auto CAD Layout | Input Voltage(V): | 80~305Vac,180-528vac |
---|---|---|---|
CRI (Ra>): | 75 | Beam Angle(°): | 40° 60° 120° 140° |
Working Lifetime(Hour): | 50000 | Lamp Body Material: | Aluminum Alloy |
Warranty(Year): | 5-Year | Lamp Luminous Efficiency(lm/w): | 130 |
Lamp Luminous Flux(lm): | 130000lm | Color Temperature(CCT): | Cool White |
Working Temperature(℃): | -40 - 60 | IP Class: | IP 65 (Upgradeable To IP 67) |
Color Temperature: | 2700-6500K | ||
High Light: | 75Ra outdoor led flood lights,1000W outdoor led flood lights,Stadium ip67 waterproof led lights |
Features:
1. 80% lumen maintenance over 50,000hours |
2. Wide Power range: 1000W |
3. 110-480Vac input voltage without additional adapter |
4. Patent Built-in Serge Protection. |
5. Top chips high efficacy 130lm/w±7% with meanwell driver |
6. IP67 waterproof, IK10 impact proof |
7. Neutral Salt Spray Resistance |
8. Anti-Corression power coating surface treatment |
9. Stainless steel brackets material.(Upgradable to SS316) |
10. 0-10VDC, DALI and wireless control available |
11. UL cUL DLC, TUV CE RoHS, CB, SAA, LM79 listed |
12. High uniformity & color rendering index |
Parameters:
Model | RGL-1000A | |
Beam Angle | 40° 60° 120° 140° | |
Stable Flux (5700K after 1 hour) |
130000lm | |
Dimension (mm) | 671*405*204 | |
LEDs | 900W | |
Power | Driver | 100W |
Consumption | Total | 1000W |
Replace HID Lamp | 2200~2500W | |
Net Weight | 30kg (66lbs) | |
Color Temperature | 2700-6500K | |
Color Rendering | ≥Ra75 (≥Ra80, ≥Ra90 available on request) | |
Working Life | ≥50000Hrs | |
Housing Material | Aluminum & Powder coating | |
Power Supply | Meanwell | |
IP Class |
IP 65 (Upgradeable to IP 67) |
|
IK Class |
IK 10 |
|
Insulation Class | Class I | |
Working Temperature | -40C ~ 60C / -40F ~ 140F | |
Working Humidity | 10% ~ 95% | |
AC Input | 110-480Vac input voltage without additional adapter | |
DC Input | 100 ~ 400Vdc, 500Vdc ~ 800Vdc | |
THD | <10% | |
Power Factor | ≥0.98 | |
Warranty | LED Module | 5 years |
Driver | 5 years | |
Housing | 10 years |
For Different application requirement, Razorlux Genius Series have different types of beam angles options.
at the moment we have 40° 60° 120° 140° beam angle available.
Application:
Razorlux’s reliable in-lighting design and technical team to ensure we deliver as promised
Razorlux continuously improves our range to deliver the best performance, with enhanced operational efficiencies, like:
1. Market-leading weight and sail area = Easy retrofit of old style luminaires, and reduced install costs
2. Meanwell drivers = Ease of maintenance
3. Patented heat sink design = Better heat dissipation in harsh environment
4. Unique design = you can not find the second supplier in the market
5. Wide selection of beam angle = you always find the best one to match with the height of installation
6. Easy installation for electricians = reduced installation costs
7. Full replacement warranty* = confidence that you are working with a company who stands behind their product
FAQ:
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
