outdoor ice rink lights
Rated Power: 400W
Input Voltage: AC90-305, DC127-431
Color Temperature: 2700K-6500K
Lamp Efficiency: 130LM/W
Beam Angle: 15°, 20°, 30°, 40°, 60°, 120°, 140°x60°.
CRI: Ra>75
IP Grade: IP67
Bracket: Stainless Steel
Net Weight: 33KG
Warranty: 5 Years
Certificate:RMRS CE, RoHS, SAA, C-Tick, UL, DLC, CB, ISO:9001
- Product Description
Professional Outdoor Ice Rink Lights - Illuminate Your Skating Paradise
When winter arrives and you're prepared to make the idealize ice skating encounter, having solid outdoor ice rink lights gets to be basic for security and satisfaction. Our professional-grade Driven lighting frameworks are particularly designed to convey remarkable execution in unforgiving winter conditions. With over 25 a long time of involvement in Driven innovation improvement, Xi'an Razorlux brings you cutting-edge light arrangements that change your open air ice arena into a well-lit, secure environment for skaters of all expertise levels.
Product Parameters
Model | RGL2-400A | |
Beam Angle | 40° 60° 120° 140° | |
Stable Flux (5700K after 1 hour) | 52000lm | |
| LEDs | 360W |
Power | Driver | 40W |
Consumption | Total | 400W |
Replace HID Lamp | 800~1000W | |
Net Weight | 15kg with stainless steel floodlight bracket | |
Color Temperature | 2700-6500K | |
Color Rendering | ≥Ra75 (≥Ra80, ≥Ra90 available on request) | |
Working Life | ≥50000Hrs | |
Housing Material | Aluminum & Powder coating | |
Power Supply | Meanwell | |
IP Class | IP 67 | |
IK Class | IK 10 | |
Insulation Class | Class I | |
Working Temperature | -40C ~ 60C / -40F ~ 140F | |
Working Humidity | 10% ~ 95% | |
AC Input | 110-480Vac input voltage without additional adapter | |
DC Input | 100 ~ 400Vdc, 500Vdc ~ 800Vdc | |
THD | <10% | |
Power Factor | ≥0.98 | |
Warranty | LED Module | 5 years |
| Driver | 5 years |
| Housing | 10 years |
Why Choose Our Outdoor Ice Rink Lights?
Our Driven lighting arrangements stand out in the competitive showcase much obliged to our protected multi-function plan and demonstrated track record. Not at all like conventional metal halide lights, our Driven frameworks create negligible warm, making a difference protect your ice surface quality. The instant-on capability guarantees full brightness promptly, indeed in solidifying temperatures. With 130 lumens per watt proficiency and different bar point alternatives, you can customize the idealize lighting format for your arena measure and requirements.
Applications
Our ice arena lighting arrangements serve assorted open air skating environments:
- Backyard Ice Arenas: Idealize for private skating ranges where families appreciate winter exercises together
- Community Amusement Centers: Perfect for civil open air arenas serving neighborhood neighborhoods and skating programs
- School Athletic Offices: Great for instructive teach with open air hockey preparing regions and physical instruction programs
- Commercial Skating Scenes: Reasonable for businesses advertising open skating, hockey associations, and skating lessons
- Professional Preparing Offices: Outlined for genuine competitors requiring high-quality light for hone and competition preparation
- Event Scenes: Extraordinary for brief or regular ice arenas at celebrations, occasion markets, and uncommon winter celebrations
- Recreational Complexes: Culminate for bigger open air offices with numerous skating regions and different skill-level programming
- Hockey Clubs: Perfect for organized groups requiring steady, glare-free lighting for hones and games
Each application benefits from our customizable color temperatures and bar points, guaranteeing ideal perceivability whereas keeping up vitality proficiency all through the skating season.
Quality Control
We keep up ISO9001 certification for 22 sequential a long time, illustrating our commitment to reliable quality. Each installation experiences thorough testing counting warm cycling, vibration resistance, and waterproof confirmation some time recently shipment.
Shipment Samples
Sample orders are accessible for assessment purposes. We give customized tests inside 7-10 trade days, permitting you to test execution and quality some time recently bulk orders.
Packaging and Transportation
Each outdoor ice rink light installation is independently pressed in defensive froth bundling. We offer different shipping choices counting discuss cargo for critical orders and ocean cargo for cost-effective bulk shipments.
| Transportation Time | Shipping Option Details | Recommend Weight |
| 3-7 days | International Express(DHL, FedEx, UPS, TNT, etc.) | 0.5KG-300KG(optimal for cost efficiency under our contarated express rates) |
| 5-10 days | By Air (Airport-to-port or Airport-to-door) | 300KG+(Significantly more economical than express shipping for heavy cargo) |
| 18-22 days | By Rail(China-Europe Railway Express) | 2CBM/500KG+(More economical than air freight for large shipment with flexible timelines) |
| 15-50 days | By Sea(FLC/LCL) | 2CBM/500KG+(Much more economical than rail,suit for non-urgent cargo, also the most cost-effective shipping method) |
Transaction Feedback
Our clients reliably report moved forward vitality reserve funds of 60-70% compared to conventional lighting frameworks, with improved perceivability and decreased support costs.
After Sales Service
We give comprehensive 5-year guarantee scope and responsive specialized bolster. Our group offers establishment direction, investigating help, and substitution parts when needed.
Qualification Certification
Our items hold numerous universal certifications counting RMRS, CE, RoHS, SAA, C-Tick, UL, DLC, and CB endorsements, guaranteeing worldwide compliance benchmarks.
FAQ
Q: How many lights do I need for a standard backyard ice rink?
A: For a typical 20x40 foot backyard rink, 4-6 of our 400W fixtures provide adequate illumination when properly positioned around the perimeter.
Q: Can these lights withstand extreme winter weather conditions?
A: Yes, our IP67-rated fixtures are designed for temperatures from -40°C to +50°C with complete protection against water and ice formation.
Q: What color temperature works best for ice hockey visibility?
A: We recommend 5000K-6000K color temperature for optimal puck and player visibility, which our lights can provide.
Q: Do these lights work immediately in freezing temperatures?
A: Absolutely. Unlike traditional lighting, our LED technology reaches full brightness instantly, even in sub-zero conditions.
Q: How do I mount these lights for my outdoor rink?
A: Our stainless steel brackets accommodate pole mounting, wall mounting, or suspended installation depending on your rink layout and preferences.
Contact Us
Ready to illuminate your skating experience with professional outdoor ice rink lights? Our lighting experts are standing by to help you design the perfect lighting solution for your specific needs.
Email: sam@razorlux.com
Transform your outdoor ice rink into a brilliantly lit skating paradise where safety meets performance, and winter nights become opportunities for endless skating enjoyment.
