Aluminum IP65 Led High Mast Light 1000W RoHS Led Baseball Field Lights

Aluminum IP65 Led High Mast Light 1000W RoHS Led Baseball Field Lights

Product Overview

The Aluminum IP65 LED High Mast Light 1000W RoHS Led Baseball Field Lights is a professional LED high-mast light for baseball stadiums, ports and big industrial complexes. This 1000W fixture produces 120,000 lumens at 130-150 lm/W efficiency. It produces the same amount of lumens as standard 2000W metal halide systems, but uses 50% less energy. It is designed for tough outdoor conditions with a die-cast aluminium housing and IP65/IK10 protection.

Aluminum IP65 Led High Mast Light 1000W RoHS Led Baseball Field Lights Specifications

Key Features

Professional baseball requires uniform illumination without glare. Our customizable lens system offers four beam angles:

· 15°: Narrow spot for 30m+ mounting heights

· 30°: Medium beam for infield coverage

· 60°: Wide flood for outfield areas

· 90°: Ultra-wide for perimeter lighting

Performance metrics:

· Uniformity ratio: ≥0.7 (meets IESNA RP-6 standards)

· UGR: <25 (glare control for player safety)

· CRI: >70 (accurate color rendering for broadcasts)

· Instant-on: No warm-up delay for game operations

Marine-Grade Durability

Built for coastal and industrial environments with:

· C5M corrosion resistance: Passes ISO 9227 salt spray testing (1,000+ hours)

· IP65 sealing: Complete dust protection + high-pressure water jet resistance

· IK10 impact rating: Withstands 20 joules of impact force

· Thermal management: Fin-array heatsink maintains <85°C junction temperature

The housing features electrophoresis coating that outperforms standard powder coating in corrosive atmospheres.

Applications

Baseball & Softball Stadiums

Provides professional play and HD transmission 500-1,500 lux lighting. Smooth slow motion replays at 120fps flicker free operation. Normal Installation: 16 lights in four 25-30m high poles around the field.

Ports & Shipping Terminals

RMRS approved for marine usage. Reliable operation in salt spray situations. 24/7 duty cycle. Perfect for container yards, loading docks and ship-to-shore crane operations.

Industrial Facilities

High bay option for 15-30m ceiling heights in factories, warehouses and distribution hubs. Uses fewer fixtures than standard high-bay clusters.

Mining & Heavy Industry

Vibrations and airborne particulates: Constant Cold start at -40°C Ambient operation at +55°C Survives harsh circumstances Impact rating IK10 for debris and machines.

Airport Aprons & Large Parking Areas

Aluminum IP65 Led High Mast Light 1000W RoHS Led Baseball Field Lights meets FAA lighting regulations with precise beam control to reduce light pollution. Wide coverage for cost efficient reduction of fixture count for wide area lighting.

Frequently Asked Questions

2000w metal halide or 1000w led?

The LED uses 50% less power for same or brighter light. You receive 120,000 lumens with greater uniformity, instant-on operation, no restrike delay. Metal halide systems likewise incur 30-40% lumen degradation during their life. Our LED has >70% output @ 100,000 hours.

What is the recommended height to mount?

Baseball fields: 20-35 m depending on the quality of the field (recreational/professional). Free Photometric Analysis with Recommendations for Fixture Placement Based on Your Needs.

Can I use dimming controls?

Yes, we offer 0-10V and DALI dimming options as customization. Dimming to 50% during practice sessions can extend energy savings beyond the base 50% reduction.

What's the installation timeline?

A typical four-pole baseball field setup (16 fixtures) takes 2-3 days with a professional crew, assuming electrical infrastructure is ready. Each fixture weighs ~35kg and includes pre-wired connections for simplified installation.

How many units fit in a shipping container?

250 units per 20-foot container. Each fixture ships in protective EPS foam Packaging with mounting hardware and installation guide included.

Can you customize mounting brackets?

Yes, we accommodate existing pole configurations. Provide your mounting interface specifications, and we'll supply compatible brackets or adapter plates.
