Outdoor Led Arena Lights

1000W Outdoor LED Arena Lights - Tournament-Grade Sports Lighting

Product Overview

Razorlux's 1000W Outdoor Led Arena Lights can change the look of your sports venue. This system gives off 130,000 lumens of light while using 70% less energy than regular metal halide lamps. It was designed for professional arenas and community centers. Fully approved for sales in all countries (UL, DLC, CE, SAA) and backed by our 5-year business warranty.

Outdoor Led Arena Lights Specifications

Why Razorlux Arena Lights?

Proven Performance Since 2006

Razorlux runs two LED study centers at the national level in Xi'an, China. There are more than 200 patents that our engineering team owns in the areas of power control systems, thermal management, and optical design. We've finished more than 500 stadium projects in 60 different countries.

What this means for you:

·Technology that has been tried in the real world

·Support for ongoing research and development for new lighting standards

·Access to application engineers who know a lot about stadiums

Broadcast-Quality Illumination

For HD and 4K broadcasting, professional sports need lighting that doesn't flicker. With high-quality drivers from Mean Well and Inventronics, our Outdoor Led Arena Lights have a flicker rate of less than 0.5%.

Performance tests:

·High-speed cameras with 1000 fps or more can use it.

·There are no rolling shutter effects when playing back in slow motion.

·Keeps colors the same across various lights (SDCM <3)

Built for Extreme Environments

No matter where you are, our taps can handle the heat, the cold, and the salt spray. The case has an IP67 grade and a two-layer powder covering that can stand up to 1000 hours of salt fog tests. Category 5 storm winds can't break stainless steel mounting clamps.

How long something lasts in real life:

·It can work in temperatures between -40°C and +55°C.

·The rust class is C5M, which is the best naval grade.

·Vibration tests based on the rules of IEC 60068-2-6

Application Solutions

Professional Sports Stadiums

Perfect for football, soccer, rugby, and cricket fields that need to meet FIFA, UEFA, or broadcast standards

Example of configuration:

· 26 to 40 meters for setting up

· Pick a spot beam with 15° or 20°.

· Most fields have between 40 and 80 pegs, but it depends on the size of the field.

It can get as bright as 500 to 2000 lux on the horizontal plane.

To keep the UGR grade below 50 for player comfort, our exact lenses get rid of dark spots between the poles.

Community Multi-Sport Complexes

Ideal for: Basketball, tennis, volleyball courts with 8-15 meter mounting heights

Configuration example:

· Beam options: 40° or 60° flood

· Typical layout: 8-16 fixtures per court

· Achieves: 200-500 lux for recreational play

The wide input voltage range (AC 90-305V) ensures stable operation even with grid fluctuations common in municipal power systems.

Equestrian & Training Arenas

Ideal for: Indoor/outdoor riding arenas requiring calm, flicker-free lighting

Why horses respond better:

· Adjustable color temperature (2700K warm white reduces skittishness)

· Zero flicker prevents startling

· CRI >75 shows true coat colors for judging

The IP67 seal prevents dust from arena footing materials from degrading internal optics.

Coastal & High-Humidity Facilities

Ideal for: Beachside courts, tropical climate venues

Corrosion protection:

· 316 stainless steel brackets (marine-grade)

· Conformal coating on PCB assemblies

· Sealed cable entries with silicone gaskets

Fixtures maintain full output in 100% humidity environments. RMRS certification confirms suitability for offshore platforms and ship deck lighting.

Technical Features

Advanced Thermal Management

Our heritage in power supply manufacturing (1998-2006) gives us unique expertise in heat dissipation. The integrated aluminum fin design maintains junction temperature below 85°C even at 55°C ambient.

Flexible Optical System

Seven beam angle options suit any venue geometry. Our TIR (Total Internal Reflection) lenses deliver precise light control with minimal spill.

Beam selection guide:

· 15°-20°: High-mast stadiums (>25m height)

· 30°-40°: Mid-height poles (15-25m)

· 60°-120°: Low mounting (<15m) or area lighting

· 140°×60° asymmetric: Perimeter wall washing

Each lens is molded from UV-stabilized polycarbonate rated for 100,000 hours of outdoor exposure.

Universal Input Power

AC 90-305V and DC 127-431V compatibility eliminates the need for step-down transformers in many international projects. Built-in surge protection (10kV) guards against lightning damage.

Installation benefits:

· Simplified electrical design

· Reduced component count

· Compatible with solar/battery backup systems (DC input)

​​​​​​​

Frequently Asked Questions

Q: How long until these lights pay for themselves?

A: Payback period is typically 18-24 months through energy savings alone. Factor in eliminated maintenance costs (no bulb changes, no ballast replacements), and ROI improves to 12-18 months for high-usage facilities.

Q: Can I retrofit existing pole structures?

A: Yes. Our fixtures weigh 15 kg versus 35-50 kg for equivalent HID systems. The reduced weight and wind load often allow reuse of existing mounting hardware. We provide structural load calculations for your engineer's review.

Q: How do these compare to other brands?

A: Independent lab testing shows our fixtures maintain higher lumen output over time. At 50,000 hours, we measure 90% of initial lumens versus industry average of 80-85%. The difference comes from superior thermal management keeping LED junction temperatures lower.

Q: What maintenance is required?

A: Minimal. In dusty environments, clean lenses annually with water and mild detergent. In clean environments, fixtures are maintenance-free for 8-10 years. No bulb changes, no ballast replacements, no ignitor failures like HID systems.

Start Your Lighting Upgrade

Razorlux has delivered energy-efficient lighting solutions to over 500 sports facilities worldwide. Our engineering team is ready to design a system tailored to your venue's specific requirements.

Next steps:

1. Share your facility dimensions and current lighting details

2. Receive a custom photometric design within 48 hours

3. Get a detailed quote including energy savings projections

Contact our Outdoor Led Arena Lights' team:

sam@razorlux.com
