High Bay Led Ufo Lights
Model No.: RHB-UA-100, RHB-UA-150, RHB-UA-200, RHB-UA-240
Rated Power: 100W, 150W, 200W,240W
Input Voltage: AC85-265V
Color Temperature: 3000-6500K Lamp Efficiency: 120lm/w Beam Angle: 60°, 120°
CRI: Ra>75
IP Grade: IP65
Dimension: Ø280*185 mm(100W), Ø340*187mm (150W), Ø400*196 mm(200W)
Net Weight: 3.8kg, 4.9kg, 6.8kg Certificate: CE, RoHS
Warranty: 5 Years
- Product Description
High Bay LED UFO Lights: Cut Energy Costs by 60% in Industrial Facilities
Razorlux's High Bay LED UFO Lights solve the three biggest problems facility managers face: high electricity bills, frequent maintenance downtime, and poor lighting quality. Our external Meanwell driver design delivers 50,000+ hours of reliable operation while using 60% less energy than traditional metal halide fixtures. With proven performance in over 2,000 installations across warehouses, manufacturing plants, and cold storage facilities, these lights pay for themselves within 18-24 months through energy savings alone.
High Bay Led Ufo Lights Specifications
| Model No. | Rated Power | Input Voltage | Color Temperature | Lamp Efficiency | Beam Angle | CRI | IP Grade | Dimension | Net Weight | Certificate | Warranty |
|---|---|---|---|---|---|---|---|---|---|---|---|
| RHB-UA-100 | 100W | AC85-265V | 3000-6500K | 120lm/w | 60°, 120° | Ra>75 | IP65 | Ø280*185 mm | 3.8kg | CE, RoHS | 5 Years |
| RHB-UA-150 | 150W | AC85-265V | 3000-6500K | 120lm/w | 60°, 120° | Ra>75 | IP65 | Ø340*187mm | 4.9kg | CE, RoHS | 5 Years |
| RHB-UA-200 | 200W | AC85-265V | 3000-6500K | 120lm/w | 60°, 120° | Ra>75 | IP65 | Ø400*196 mm | 6.8kg | CE, RoHS | 5 Years |
| RHB-UA-240 | 240W | AC85-265V | 3000-6500K | 120lm/w | 60°, 120° | Ra>75 | IP65 | Ø400*196 mm | 6.8kg | CE, RoHS | 5 Years |
Product Overview
What Makes Our UFO Lights Different?
External Driver Architecture
Unlike competitors who hide drivers inside the fixture, our external Meanwell driver stays cooler and lasts longer. When maintenance is needed (rarely), you replace just the driver—not the entire unit.
Real-World Performance
· Lumileds/Samsung LED chips: 135lm/w system efficiency
· Operates -20°C to +50°C without performance loss
· IP65 waterproof rating withstands dust and moisture
· 5-year warranty (industry average: 3 years)
Four Power Options for Any Space
Model | Power | Best For | Replaces |
RHB-UA-100 | 100W | 15-20ft ceilings | 250W MH |
RHB-UA-150 | 150W | 20-25ft ceilings | 320W MH |
RHB-UA-200 | 200W | 25-30ft ceilings | 400W MH |
RHB-UA-240 | 240W | 30-35ft ceilings | 500W MH |
Key Benefits
Faster Installation
Single-point mounting takes 5 minutes per fixture. Wide voltage input (AC85-265V) works with existing wiring—no electrician needed for voltage conversion.
Better Light Quality
· Flicker-free output reduces worker eye strain
· CRI >80 option for color-critical tasks
• Instant-on (no 10-minute warm-up as HID bulbs need)
• Select 60° beam for high ceilings or 120° for even coverage
Where They Work Best
Warehouses & Distribution Centers
60° beam spread fixtures high installed to concentrate light along aisles. Low-activity times get 40% energy consumption reduction with dimming capabilities.
Manufacturing Plants
IP65 protection handles dust and coolant spray. External drivers stay accessible for rare maintenance without stopping production.
Cold Storage Facilities
Full brightness maintained at -20°C. Sealed housing prevents condensation damage common in temperature-transition zones.
Retail & Showrooms
Sleek UFO design complements modern interiors. Adjustable color temps create warm (3000K) or bright (5000K) ambiance.
Why Razorlux?
We recommend upgrading the lighting system to High Bay Led Ufo Lights.
18 Years of LED Innovation
Since 2006, we've focused exclusively on industrial LED lighting. Our engineering team holds 200+ patents in thermal management and driver technology.
Certified Quality Standards
· ISO9001 certified manufacturing since 2001
· Two government-approved research labs (National Development and Reform Commission, Ministry of Science and Technology)
· Every batch tested to LM-80 standards
Proven Track Record
2000+ deployments at Fortune 500 facilities. Clients include shipping firms, food processors and automobile manufacturers in more than 40 countries.
Common Questions
How many lights do I require?
25ft ceilings design one 200W fixture for every 400-500 sq ft. Free Dialux lighting simulations for projects above 20 units.
Can I turn the lights down a little?
Yes. Standard 0-10V dimming compatible with motion sensors and daylight harvesting systems.
Do they light up on camera?
No. High-frequency drivers prevent flicker that may be picked up by video cameras or sensitive devices.
How long until I break even?
Most clients see ROI within 18-24 months through energy savings alone. Factor in eliminated maintenance costs, and payback accelerates to 12-15 months.
