outdoor tennis lights

Patented Multi-function design, suitable for all working environments.
Rated Power: 500W
Input Voltage: AC90-305, DC127-431
Color Temperature: 2700K-6500K
Lamp Efficiency: 130LM/W
Beam Angle: 15°, 20°, 30°, 40°, 60°, 120°, 140°x60°.
CRI: Ra>75
IP Grade: IP67
Bracket: Stainless Steel
Net Weight: 22KG
Warranty: 5 Years
Certificate:RMRS CE, RoHS, SAA, C-Tick, UL, DLC, CB, ISO:9001

Send Inquiry Download

Product Description

500W Professional Outdoor Tennis Lights | Tournament-Grade Performance

Playing tennis under poor lighting ruins the game. Shadows hide the ball. Glare blinds players during serves. Your members complain and leave.

Our 500W outdoor tennis lights system solves these problems withprofessional-grade illuminationthat meets ITF international standards. Since 2006, we've lit over 300 tennis facilities across 45 countries – from Olympic training centers to community clubs.

product-1-1

Outdoor Tennis Lights Specifications

Model		RGL2-500P
Beam Angle		15° 20° 30°
Stable Flux (5700K after 1 hour)		60000lm
	LEDs	450W
Power	Driver	50W
Consumption	Total	500W
Replace HID Lamp		1000~1200W
Net Weight		19kg with stainless steel floodlight bracket
Color Temperature		2700-6500K
Color Rendering		≥Ra75 (≥Ra80, ≥Ra90 available on request)
Working Life		≥50000Hrs
Housing Material		Aluminum & Powder coating
Power Supply		Meanwell
IP Class		IP 67
IK Class		IK 10
Insulation Class		Class I
Working Temperature		-40C ~ 60C / -40F ~ 140F
Working Humidity		10% ~ 95%
AC Input		110-480Vac input voltage without additional adapter
DC Input		100 ~ 400Vdc, 500Vdc ~ 800Vdc
THD		<10%
Power Factor		≥0.98
Warranty	LED Module	5 year
	Driver	5 year
	Housing	10 year

product-1-1

Three Critical Problems We Solve

Problem1: High Energy Bills

Traditional metal halide lightswaste 70% more electricity than necessary.

Our Solution:130 lumens per watt efficiency cuts your power consumption dramatically.

Problem2: Poor Visibility During Play

Uneven lighting creates dark patches where the ball "disappears" mid-rally.

Our Solution:Professional uniformity ratio (>0.7) ensures consistent brightness across the entire court. Players track the ball effortlessly from baseline to net.

product-1-1

Problem3: Neighbor Complaints

Light spilling into nearby homes creates conflicts with residential communities.

Our Solution:Asymmetric optics direct 100% of light onto the court surface. Zero upward spill means dark-sky compliance and happy neighbors.

product-1-1

Who This Lighting System Is Built ForProfessional & Tournament Venues

Host sanctioned competitions with confidence. Our outdoor tennis lights system delivers:

· ITF Class I standards (750+ lux)

· Flicker-free for 4K broadcasting

· Consistent illumination for high-speed play

Recent Projects:Davis Cup qualifying venues, National Championship courts

product-1-1

Municipal Sports Complexes
Reduce maintenance headaches and operational costs:
· 70% lower energy consumption
· Minimal maintenance (10-year lifespan)
· Flexible layouts for multi-court facilities
Private Tennis Clubs
Keep members happy with premium playing conditions:
· Glare-free optics for comfortable evening play
· Instant-on technology (no warm-up wait)
Customizable light levels for practice vs. matches

product-1-1

Coastal & Extreme Climate Locations

Survive salt spray, hurricanes, and harsh weather:

· Military-grade corrosion protection

· 20kV surge protection against lightning

· Wind-rated for 150+ mph storms

product-1-1

What Makes Razorlux Different

18 Years of Specialized Experience

We've done nothing but sports lighting since 2006. Our engineering team includes 10 PhDs focused exclusively on LED optics and thermal management.

Not a general lighting company trying to sell everything.We understand tennis-specific requirements.

Complete Design Service (No Guesswork)

Send us your court layout. Within 48 hours, you'll receive:

· Custom photometric analysis

· Precise fixture placement plan

· 3D visualization of light distribution

· Detailed ROI calculation

Real Support When You Need It

· Direct engineer access (not a call center)

· 24-hour response time

· Spare parts inventory in 5 global warehouses

· Video troubleshooting assistance

product-1-1

Common Questions (Honest Answers)

Q: "Are these really bright enough for competitive play?"

A: Yes. We've lit courts hosting professional tournaments including ATP Challenger events. Our system exceeds ITF Class I requirements (750+ lux with strict uniformity). We'll provide photometric proof before you order.

Q: "What happens if one fixture fails during a match?"

A: Each fixture operates independently. If one fails (rare with our 50,000-hour rating), the others continue working. We ship replacement units via express service – typically arriving within 3 business days.

Q: "How difficult is installation?"

A: Most installations complete in 1-2 days for a 4-court facility. The fixtures work with existing pole infrastructure (up to 15m height). We provide detailed installation guides and video support.

Q: "Can I dim the lights for practice sessions?"

A: Yes. We offer optional 0-10V or DALI dimming controls. Reduce brightness during casual play to save additional energy and extend fixture lifespan.

Q: "What's the actual payback period?"

A: Most facilities break even within 2-3 years through energy savings alone. Factor in reduced maintenance costs, and ROI often comes sooner.
