led arena floodlights
Rated Power: 270W
Input Voltage: AC90-305, DC127-431
Color Temperature: 2700K-6500K
Lamp Efficiency: 130LM/W
Beam Angle: 15°, 20°, 30°, 40°, 60°, 120°, 140°x60°.
CRI: Ra>75
IP Grade: IP67
Bracket: Stainless Steel
Net Weight: 15KG
Warranty: 5 Years
Certificate:RMRS CE, RoHS, SAA, C-Tick, UL, DLC, CB, ISO:9001
- Product Description
Professional LED Arena Floodlights - Stadium Lighting Solutions
When you require dependable, high-performance stadium lighting, our led arena floodlights provide remarkable brightness and toughness. Planned for sports complexes, fields, and huge settings, these professional-grade installations give uniform brightening that meets worldwide benchmarks. Our lights highlight progressed warm administration and accuracy optics, guaranteeing ideal execution in requesting situations. With over 25 a long time of lighting mastery, Razorlux conveys lighting arrangements that upgrade perceivability and security for competitors and onlookers alike.
Product Specifications
Model | RGL-270P | |
Beam Angle | 20° | |
Stable Flux (5700K after 1 hour) | 29700 lm | |
Dimension (mm) | 360*358*306 | |
| LEDs | 243W |
Power | Driver | 27W |
Consumption | Total | 270W |
Replace HID Lamp | 600~1000W | |
Net Weight | 8kg(17.6lbs) | |
Color Temperature | 2000-6000K | |
Color Rendering | ≥Ra75 (≥Ra80, ≥Ra90 available on request) | |
Working Life | ≥50000Hrs | |
Housing Material | Aluminum & Powder coating | |
Power Supply | Meanwell | |
IP Class | IP 67 | |
IK Class | IK 10 | |
Insulation Class | Class I | |
Working Temperature | -40C ~ 60C / -40F ~ 140F | |
Working Humidity | 10% ~ 95% | |
AC Input | 80-315Vac input voltage without additional adapter | |
DC Input | 80 ~ 400Vdc | |
THD | <10% | |
Power Factor | ≥0.98 | |
Warranty | LED Module | 5 year |
| Driver | 5 year |
| Housing | 10 year |
Why Choose Our LED Arena Floodlights?
Our licensed multi-function plan adjusts to all working situations. You get prevalent warm administration innovation that expands installation life expectancy whereas keeping up reliable light yield. The precision-engineered optics dispense with glare and give uniform field illumination.
Your venture is ensured by our 5-year guarantee and military-grade quality control framework. We've kept up ISO9001 certification for 22 sequential a long time, guaranteeing each installation meets the most elevated standards.
With numerous pillar point choices, you can customize the lighting format for your particular setting prerequisites. The strong stainless steel bracket withstands unforgiving climate conditions and gives secure mounting.
Applications
Our stadium lighting installations serve differing scene requirements:
• Sports Stadiums: Football, soccer, and baseball areas requiring tall consistency and anti-glare performance
• Indoor Fields: Ball courts, volleyball courts, and multi-purpose sports facilities
• Tennis Courts: Proficient and recreational courts requiring exact lighting control and color rendering
• Athletic Preparing Offices: Indoor and open air preparing complexes with changing light needs
• Recreational Centers: Community sports offices and school athletic fields
• Horse Hustling Tracks: Oval tracks requiring wide-area scope and great visibility
• Cricket Grounds: Huge field brightening with negligible shadow casting
• Ice Hockey Arenas: Cold-environment applications with steady execution requirements
• Swimming Pool Complexes: Oceanic centers requiring water-resistant, high-performance lighting
• Occasion Settings: Multi-purpose offices facilitating sports occasions, concerts, and exhibitions
Quality Control
We actualize thorough testing conventions all through fabricating. Each led arena floodlights unit experiences warm cycling, vibration testing, and photometric confirmation. Our quality affirmation group performs 100% pre-shipment assessment to guarantee top performance.
Our DFEMA disappointment mode examination framework, received from car industry measures, distinguishes potential issues some time recently they happen. This proactive approach ensures unwavering quality in basic applications.
Shipment Samples
We give comprehensive inspecting administrations to confirm execution some time recently bulk orders. Test bundles incorporate point by point photometric reports, establishment rules, and specialized details. This permits you to assess light quality, pillar designs, and mounting compatibility.
Packaging and Transportation
Each installation gets defensive froth bundling inside strengthened cartons. We offer adaptable shipping choices counting discuss cargo for critical ventures and ocean cargo for cost-effective bulk orders. Rail transport gives an proficient middle-ground arrangement for mainland deliveries.
| Transportation Time | Shipping Option Details | Recommend Weight |
| 3-7 days | International Express(DHL, FedEx, UPS, TNT, etc.) | 0.5KG-300KG(optimal for cost efficiency under our contarated express rates) |
| 5-10 days | By Air (Airport-to-port or Airport-to-door) | 300KG+(Significantly more economical than express shipping for heavy cargo) |
| 18-22 days | By Rail(China-Europe Railway Express) | 2CBM/500KG+(More economical than air freight for large shipment with flexible timelines) |
| 15-50 days | By Sea(FLC/LCL) | 2CBM/500KG+(Much more economical than rail,suit for non-urgent cargo, also the most cost-effective shipping method) |
Transaction Feedback
Client fulfillment drives our ceaseless change endeavors. We collect point by point input on item execution, establishment encounter, and long-term unwavering quality. This input specifically impacts our inquire about and advancement priorities.
After Sales Service
Our comprehensive back incorporates specialized interview, substitution portion supply, and guarantee claim handling. Inaccessible diagnostics offer assistance resolve issues rapidly, whereas our worldwide benefit arrange gives nearby back when needed.
We keep up nitty gritty benefit records for each establishment, empowering proactive upkeep proposals and execution optimization.
Qualification Certification
Our certifications illustrate compliance with universal measures. RMRS certification approves marine applications, whereas UL posting guarantees North American advertise compliance. TÜV certification covers European prerequisites, and SAA endorsement empowers Australian establishments.
FAQ
Q: What beam angle works best for large stadium applications?
A: For comprehensive stadium coverage, we recommend combining 20° narrow beam fixtures for long-distance projection with 60° wide beam units for near-field illumination.
Q: How do these fixtures perform in extreme weather conditions?
A: Our IP67 rating ensures complete protection against dust and temporary water immersion. The robust housing withstands temperature extremes from -40°C to +50°C.
Q: Can the color temperature be customized for broadcast applications?
A: Yes, we offer custom color temperature options from 2700K to 6500K to meet specific broadcast and television requirements.
Q: What dimming options are available?
A: Our lights support 0-10V and DALI dimming protocols, allowing precise light level control for different event types.
Q: How long is the typical installation process?
A: Installation time varies by venue size, but most arena projects complete within 2-3 weeks including testing and commissioning phases.
Contact Us
For detailed specifications, custom quotes, or technical consultation, reach out to our led arena floodlights specialists:
Email: sam@razorlux.com
Our team provides comprehensive support from initial consultation through long-term maintenance, ensuring your lighting investment delivers optimal performance for years to come.
