led baseball field lights
Rated Power: 1000W
Input Voltage: AC90-305, DC127-431
Color Temperature: 2700K-6500K
Lamp Efficiency: 130LM/W
Beam Angle: 15°, 20°, 30°, 40°, 60°, 120°, 140°x60°.
CRI: Ra>75
IP Grade: IP67
Bracket: Stainless Steel
Net Weight: 32KG
Warranty: 5 Years
Certificate:RMRS CE, RoHS, SAA, C-Tick, UL, DLC, CB, ISO:9001
- Product Description
Led Baseball Field Lights - Professional Sports Lighting Solutions
Product Introduction
Change your baseball field with our proficient led baseball field lights outlined for prevalent execution and solidness. Our 1000W high-intensity lighting frameworks provide extraordinary brightening for competitive sports settings. These installations highlight progressed multi-function plan with protected innovation that adjusts to different open air situations. With 130LM/W proficiency and adaptable pillar points, you get ideal light dissemination over your whole field. Each unit gives reliable, flicker-free lighting that upgrades player execution and onlooker experience.
Specification
Model | RGL-1000A | |
Beam Angle | 40° 60° 120° 140° | |
Stable Flux (5700K after 1 hour) | 130000lm | |
Dimension (mm) | 671*405*379 | |
| LEDs | 900W |
| Driver | 100W |
| Total | 1000W |
Replace HID Lamp | 2000~3000W | |
Net Weight | 29kg (66lbs) | |
Color Temperature | 2700-6500K | |
Color Rendering | ≥Ra75 (≥Ra80, ≥Ra90 available on request) | |
Working Life | ≥50000Hrs | |
Housing Material | Aluminum & Powder coating | |
Power Supply | Meanwell | |
IP Class | IP 65 (Upgradeable to IP 67) | |
IK Class | IK 10 | |
Insulation Class | Class I | |
Working Temperature | -40C ~ 60C / -40F ~ 140F | |
Working Humidity | 10% ~ 95% | |
AC Input | 80~305Vac | |
DC Input | 100 ~ 400Vdc, 500Vdc ~ 800Vdc | |
THD | <10% | |
Power Factor | ≥0.98 | |
Warranty | LED Module | 5 years |
| Driver | 5 years |
| Housing | 10 years |
Why Choose Our Led Baseball Field Lights?
Superior Light Quality: Our installations convey uniform light with negligible glare. This guarantees players can track fast-moving balls accurately.
Energy Effective: Spare up to 60% on power costs compared to conventional metal halide frameworks. The 130LM/W productivity diminishes operational costs significantly.
Weather Safe: IP67 assurance rating implies these lights withstand rain, snow, and extraordinary temperatures. Your speculation remains ensured year-round.
Long Life expectancy: With 50,000+ hour life expectancy, you'll appreciate a long time of dependable operation with negligible support requirements.
Flexible Establishment: Numerous pillar points permit customized lighting formats. Whether you require wide surge scope or centered spotlighting, we've got you covered.
Professional Certifications: Our comprehensive certifications guarantee compliance with worldwide security and execution standards.
Applications
Our led baseball field lights serve different sports and open air lighting needs:
- Professional Baseball Stadiums: Major association offices requiring broadcast-quality lighting with exact color rendering and negligible flicker
- High School Baseball Areas: Cost-effective arrangements for instructive teach looking for solid evening diversion capabilities
- Little Alliance Parks: Secure, energy-efficient lighting for youth sports programs with lower working budgets
- Multi-Purpose Sports Complexes: Flexible lighting frameworks that oblige baseball, softball, and other field sports
- Training Offices: Indoor and secured hone ranges requiring steady, high-quality illumination
- Recreational Parks: Civil offices serving community baseball associations and casual players
- College Campuses: College athletic divisions overhauling maturing lighting infrastructure
- Corporate Sports Offices: Company-sponsored areas and worker amusement areas
- Tournament Scenes: Brief or lasting establishments for territorial and national baseball competitions
- Broadcasting Offices: Proficient scenes requiring particular lighting measures for tv and spilling coverage
Quality Control
We keep up thorough quality guidelines through our ISO9001-certified fabricating handle. Each installation experiences comprehensive testing counting warm cycling, vibration resistance, and photometric confirmation. Our quality control group performs 100% assessment some time recently shipment. We utilize progressed testing hardware to confirm lumen yield, color consistency, and electrical security. Each component meets worldwide measures for unwavering quality and performance.
Shipment Samples
We give test units for assessment some time recently bulk orders. Test testing permits you to confirm light quality, mounting compatibility, and execution characteristics. Our designing group can help with photometric calculations and format proposals. Test orders regularly dispatch inside 3-5 trade days through express dispatch. This hands-on assessment guarantees total fulfillment with your lighting investment.
Packaging and Transportation
Each fixture is individually packed in custom foam inserts within sturdy cardboard cartons. We use shock-resistant Packaging materials to prevent damage during transit. Our logistics team coordinates air freight, ocean shipping, or ground transportation based on your timeline requirements. All shipments include detailed packing lists and tracking information. We work with reliable carriers to ensure safe, timely delivery worldwide.
| Transportation Time | Shipping Option Details | Recommend Weight |
| 3-7 days | International Express(DHL, FedEx, UPS, TNT, etc.) | 0.5KG-300KG(optimal for cost efficiency under our contarated express rates) |
| 5-10 days | By Air (Airport-to-port or Airport-to-door) | 300KG+(Significantly more economical than express shipping for heavy cargo) |
| 18-22 days | By Rail(China-Europe Railway Express) | 2CBM/500KG+(More economical than air freight for large shipment with flexible timelines) |
| 15-50 days | By Sea(FLC/LCL) | 2CBM/500KG+(Much more economical than rail,suit for non-urgent cargo, also the most cost-effective shipping method) |
Transaction Feedback
Our clients reliably rate our items and benefit exceedingly. Numerous clients report critical vitality reserve funds and made strides lighting quality after updating to our frameworks. Proficient installers appreciate our nitty gritty documentation and specialized back. Office supervisors esteem the decreased support prerequisites and long-term unwavering quality. We keep up straightforward communication all through the whole exchange process.
After Sales Service
We give comprehensive post-installation back counting specialized help, substitution parts, and guarantee benefit. Our client benefit group reacts to request inside 24 hours. We offer inaccessible investigating and on-site bolster when required. Normal upkeep rules offer assistance maximize installation life expectancy. Our 5-year guarantee covers fabricating surrenders and execution issues.
Qualification Certification
Our fabricating office holds ISO9001 certification for quality administration frameworks. Led baseball field lights carry UL posting for North American markets and CE stamping for European compliance. We keep up RMRS certification for marine applications and SAA endorsement for Australian markets. DLC capability guarantees utility discount qualification. All certifications experience normal reviews to keep up legitimacy.
FAQ
Q: How many fixtures do I need for a standard baseball field?
A: Typically 6-8 poles with 2-4 fixtures each, depending on field dimensions and light levels required. We provide free lighting calculations to determine optimal layouts.
Q: What's the difference between various beam angles?
A: Narrow angles (15°-30°) provide focused, long-distance illumination. Wide angles (60°-120°) offer broad area coverage. Mixed configurations optimize field uniformity.
Q: Can these lights be dimmed?
A: Yes, our fixtures support 0-10V and DALI dimming protocols. This allows you to adjust light levels for different activities or energy conservation.
Q: How do these compare to metal halide fixtures?
A: Our LED systems use 60% less energy, last 5x longer, provide instant-on operation, and eliminate lamp replacement costs.
Q: What maintenance is required?
A: Minimal maintenance needed. Periodic cleaning of lens surfaces and visual inspection of mounting hardware. No lamp replacements required.
Contact Us
Ready to upgrade your led baseball field lights? Our lighting specialists are here to help you design the perfect solution. contact us for technical specifications, pricing, or project consultation.
