12v led flood lights waterproof
Rated Power: 90W
Input Voltage: AC90-305, DC127-431
Color Temperature: 2700K-6500K
Lamp Efficiency: 130LM/W
Beam Angle: 15°, 20°, 30°, 40°, 60°, 120°, 140°x60°.
CRI: Ra>75
IP Grade:IP67
Bracket: Stainless Steel
Net Weight: 15KG
Warranty: 5 Years
Certificate: RMRS, CE, RoHS, SAA, C-Tick, UL, DLC, CB, ISO:9001
- Product Description
12V Led Flood Lights Waterproof With Photocell
Get rid of the need for manual lighting control with our smart photocell flood light system.This 12v led flood lights waterproof turns on automatically when it gets dark and turns off when it lightens up, adjusting to changes in daylight throughout the seasons without needing any setup.Built with IP67 weather protection and covered by a 5-year warranty, it offers trouble-free operation for warehouses, parking areas, and other outdoor spaces that need dependable 24/7 security lighting.

12V Led Flood Lights Waterproof Specifications
Model | RGL-90A | |
Beam Angle | 60° 120° 140°*60° | |
Stable Flux (5700K after 1 hour) | 10800lm | |
Dimension (mm) | 360*358*306 | |
| LEDs | 81W |
Power | Driver | 9W |
Consumption | Total | 90W |
Replace HID Lamp | 150~250W | |
Net Weight | 10kg | |
Color Temperature | 2000-6000K | |
Color Rendering | ≥Ra75 (≥Ra80, ≥Ra90 available on request) | |
Working Life | ≥50000Hrs | |
Housing Material | Aluminum & Powder coating | |
Power Supply | Meanwell | |
IP Class | IP 67 | |
IK Class | IK 10 | |
Insulation Class | Class I | |
Working Temperature | -40C ~ 60C / -40F ~ 140F | |
Working Humidity | 10% ~ 95% | |
AC Input | 80-315Vac input voltage without additional adapter | |
DC Input | 80 ~ 400Vdc | |
THD | <10% | |
Power Factor | ≥0.98 | |
Warranty | LED Module | 5 year |
| Driver | 5 year |
| Housing | 10 year |

Why Choose Photocell-Integrated Flood Lights?
Automated Energy Savings
The built-in light sensor checks the amount of natural light in real-time and turns the light on only when needed.This stops lights from running when there’s still daylight, which is a common problem with lights that are turned on manually or set with poor timers.
Zero Maintenance Scheduling
Unlike systems that need to be adjusted with the seasons, the light sensor works automatically and changes with the sunrise and sunset throughout the year.
This means your building gets the right amount of light without needing anyone to check or change anything.
Precision Light Control
Special circuits with a delay of 3 to 15 seconds stop the light from turning on or off because of things like car headlights or lightning.
The sensor of 12v led flood lights waterproof only responds to slower, steady changes in natural light, which makes the system work well even in busy areas.

Ideal Applications
Warehouse & Logistics Facilities
Areas like around the outside of the building and loading docks can be automatically lit during nighttime shifts.
The light has an IP67 rating, which means it can handle dust, water, and extreme temperatures that are common in these places.
Parking Lots & Retail Centers
The lights turn on as the sun goes down, making sure people are safe.
The light sensor doesn’t need to be changed with the seasons, which helps save time for those managing the building.
Municipal Infrastructure
For places like bridges, tunnels, and parks, which might not have easy access for turning lights on or off manually, this system offers reliable lighting that can handle tough weather and possible damage.

Architectural & Signage Lighting
Facades and signs stay lit consistently without needing to be checked or maintained.
The system naturally adjusts for changes like daylight saving time and the seasons.

Frequently Asked Questions
Q: Why does the light flicker or flash sometimes?
This usually happens when the light from the fixture shines back onto the sensor.Change the angle of the light or add a cover to stop the light from reaching the sensor.
Q: Will the sensor stop working if it gets direct sunlight?
The sensor is made of a special type of plastic that stays strong in the sun.It works properly for the full 50,000 hours the light is supposed to last.
Q: Can I make the light dimmer at night?
Standard sensors only turn lights on or off.If you want the light to be dimmer, like 30% at midnight, you need to order a model that can be dimmed with a 0-10V system.
Q: How does the sensor deal with quick lights like car headlights?
The system has a delay that only triggers when the light lasts for 3 to 15 seconds.This stops the light from turning on or off because of quick flashes while still responding to the gradual changes of morning and evening.
Q: What if the sensor stops working before the light?
We use sensors that last as long as the light itself.If the sensor does fail, you can turn the light on manually or replace the sensor without replacing the whole light.
Contact Us
For project-specific requirements, custom configurations, or technical support:
Contact our 12v led flood lights waterproof's team: sam@razorlux.com
